Startech.Com
StarTech.com RKCOND17HD Dual Rail Rackmount Kvm RKCOND17HD
(No reviews yet)
Write a Review
- UPC:
- 0065030872515
- MPN:
- RKCOND17HD
- Condition:
- New
- Availability:
- Available to Order: 3 - 4 weeks leadtime
Description
1080p Display | 17 Inch | 1U | DVI & VGA Interface | Cables Included
Providing centralized control of your single PC or dozens of servers, this dual rail rackmount KVM console also gives you easy access to and visibility of your system while it�s mounted in a server rack or cabinet.
Dual Rail Design
The dual rail KVM console design maximizes space in your datacenter�s rack cabinets by allowing the LCD monitor and the keyboard/mouse to move separately from each other. You can tuck the keyboard away while the display stays active, allowing you to conveniently monitor your computer through closed glass or mesh rack cabinet doors.
High Definition LCD Monitor
The 1080p KVM console is 17.3� and LED back-lit, for low power consumption. It supports high definition resolutions up to 1920x1080 providing sharper video performance.
Digital & Analog Support
Whether you are running a multi-port KVM with an analog display or a single port KVM with a high definition display, this DVI/ VGA KVM console can support both signals.
Simple Setup
This KVM console comes with everything you need to set up:
? 1 Audio Cable? 1 Set of KVM Cables (USB/VGA)? 2 Rear Mounting Brackets? M5 Cage Nuts and Screws
Once your KVM console is mounted to your rack, you can use the USB port on the front to easily connect any USB compatible peripheral such as a fingerprint scanner or mousethumb drive.
StarTech.com offers a wide selection of KVM consoles to help you access your systems more efficiently without the expense and clutter of extra peripherals. This dual rail KVM console is backed by a 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Flexible Design: Rackmount KVM console w/ dual rails that allow the screen & keyboard to be pulled in & out independently, perfect for system monitoring as needed and to be put away when not in use
- High Definition: Rack mount monitor w/high-resolution widescreen (16:9) 1080p LCD panel perfect for applications needing extra detail or substantial info on one screen E.g. IP camera monitoring
- Versatile Interfaces: 17.3" Active Matrix TFT 16:9 widescreen
Certificates
Certification
CE, FCC, UL, REACH
Display
Aspect ratio
16:9
Contrast ratio (typical)
650:1
Display
TFT LCD
Display brightness
250 cd/m�
Display diagonal
17.3 "
Display number of colours
262144 colours
Display resolution
1920 x 1080 Pixels
Display type
LCD
On Screen Display (OSD)
No
Pixel pitch
0.199 x 0.199 mm
Response time
8 Millisecond
Supported resolutions
1024x576 1152x648 1280x720 1366x76 1600x900 1920x1080
Viewing angle, horizontal
140 �
Viewing angle, vertical
120 �
Keyboard
Hot keys
Yes
Logistics data
Master (outer) case height
13.3 cm
Master (outer) case length
84 cm
Master (outer) case width
68 cm
Products per master (outer) case
1 pc(s)
Operational conditions
Operating temperature (T-T)
0 - 40 �C
Storage temperature (T-T)
-20 - 60 �C
Package dimensions
Depth (package,cm)
84 cm
Gross Weight (Package, kg)
15.6 kg
Height (package,cm)
13.3 cm
Width (package,cm)
68 cm
Packaging content
Cables included
Audio (3.5mm), KVM
Cage nuts included
Yes
Included power plug types
ANZ, EU, JP, NA, UK
Mounting brackets included
Yes
Number of cage nuts
8
Number of screws
8
Quick installation guide
Yes
Screws included
Yes
Ports & interfaces
3.5 mm (1/8-inch) in
Yes
3.5 mm (1/8-inch) out
Yes
DVI connector type
DVI-D
DVI input ports
1
DVI output ports
1
Keyboard port type
USB
Mouse port type
USB
USB 2.0 Type-A ports quantity
2
USB 2.0 Type-B ports quantity
1
Video port type
DVI/VGA
Power
AC adapter input voltage
100 - 240 V
Input current
1 A
Power consumption (typical)
19.4 Watt
Product dimensions
Net Weight (Product, kg)
12 kg
Product Depth
72.7 cm
Product Height
4.4 cm
Product Width
48 cm
Technical details
LED indicators
Yes
Material
Steel
Mean time between failures (MTBF)
44230 Hour
Operating relative humidity (H-H)
0 - 80 %
Product colour
Black
Rack capacity
1U
Rack mounting
Yes
Sustainability certificates
RoHS
Vendor information
Brand Name
StarTech.com
Warranty
1 Year(s)
Weight & dimensions
Mounting depth (max)
100 cm
Mounting depth (min)
65 cm
