StarTech.com ST5GPEXNB 5G Pcie Network Adapter Card ST5GPEXNB

Add an Ethernet port to a PC client, server or workstation supporting four network speeds: 5G/2.5G/1G/100Mbps

This 4-speed NBASE-T PCIe network card offers an inexpensive network upgrade solution, providing access to your network at multiple speeds up to 5G, using your existing Cat5e copper cabling.

Cost-effective Multi-Gigabit Ethernet

Fully compliant with 2.5GBASE-T, 5GBASE-T, and NBASE-T (Draft IEEE802.3bz) specifications, the PCIe NIC offers a cost-effective and versatile networking solution. It provides additional bandwidth at multiple speeds, to meet your network needs without the expense of overhauling your existing cable infrastructure.

Advanced technology for optimal performance

The featured NBASE-T technology and multi-gigabit speeds support Cisco campus switches, including Catalyst 4500E, 3850 and 3560-CX. The Marvell 88E2010 chipset is optimized for achieving 2.5 and 5G rates over your existing Cat5e copper cable setup without upgrading to the more expensive Cat6A cabling required for 10Gbps speeds.

Operating efficiency and flexible use

The Tehuti Networks TN4010 chipset, compliant with IEEE 802.3az, ensures peak operating efficiency with reduced power consumption. The network card also supports 9K jumbo frames, 802.1q VLAN tagging and is backward compatible with 1000BASE-T. For additional versatility, the controller card is equipped with a standard-profile bracket and includes a low-profile bracket for installation in small form-factor computers.

The ST5GPEXNB is backed by a StarTech.com 2-year warranty.

The StarTech.com Advantage

- 1 PORT 5GbE NETWORK CARD: Single port 5Gbps PCIe Network Adapter Card provides 5x speed of standard Gigabit Ethernet to desktop/server leveraging existing infrastructure of Cat5e, CAT6, or CAT6a cable
- TECH SPECS: 5 Gbps Multi-Gigabit
- 1x RJ45

Design



Certification



CE, FCC


Chipset



Tehuti - TN4010, Marvell - 88E2010P


Internal



Yes


LED indicators



Activity, Link


Product colour



Black


Logistics data



Harmonized System (HS) code



85176990


Master (outer) case height



36 cm


Master (outer) case length



59 cm


Master (outer) case width



31 cm


Products per master (outer) case



80 pc(s)


Network



Auto MDIX IEEE



Yes


Auto-negotiation



Yes


Copper ethernet cabling technology



100BASE-TX, 1000BASE-T


Ethernet interface type



Gigabit Ethernet


Ethernet LAN



Yes


Ethernet LAN data rates



10, 100, 1000, 2500, 5000


Full duplex



Yes


Jumbo frames



9000


Jumbo frames support



Yes


Maximum data transfer rate



5000 Mbit/s


Networking standards



IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3bz, IEEE 802.3u


VLAN tagging



Yes


Operational conditions



Operating relative humidity (H-H)



10 - 90 %


Operating temperature (T-T)



0 - 70 �C


Storage temperature (T-T)



-40 - 85 �C


Package dimensions



Depth (package,cm)



17 cm


Gross Weight (Package, kg)



0.26 kg


Height (package,cm)



3 cm


Width (package,cm)



14.2 cm


Packaging content



Manual



Yes


Packaging data



Drivers included



Yes


Low-profile bracket



Yes


Ports & interfaces



Connectivity technology



Wired


Ethernet LAN (RJ-45) ports



1


Host interface



PCI Express


Interface



Ethernet


PCI version



2.0


Product dimensions



Net Weight (Product, kg)



0.2 kg


Product Depth



8 cm


Product Height



2 cm


Product Width



12 cm


Sustainability



Sustainability certificates



RoHS


System requirements



Linux operating systems supported



Yes


Mac operating systems supported



Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave


Server operating systems supported



Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019


Windows operating systems supported



Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64


Vendor information



Brand Name


StarTech.com


Warranty



1 Year(s)
