Startech.Com
StarTech.com SV1631DUSBU 16 PORT USB KVM SWITCH SV1631DUSBU
(No reviews yet)
Write a Review
- UPC:
- 0065030837224
- MPN:
- SV1631DUSBU
- Condition:
- New
- Availability:
- Available to Order: 3 - 4 weeks leadtime
Description
Control up to 16 USB computers from a single keyboard, mouse and monitor
The SV1631DUSBU 16 Port 1U Rack Mountable USB KVM Switch with OSD lets you control 16 USB computers from a single console (USB keyboard, USB mouse, VGA monitor).
Convenient push-button and hot-key controls provide quick, reliable switching between connected computers while manual and auto-scan switching modes and an On Screen Display (OSD) offer additional control options.
Designed to ensure maximum space efficiency, the USB KVM switch features a slim 1U design that fits neatly into a server equipment rack/cabinet with the included brackets, and can be cascaded with multiple KVM switches to deliver control of up to 136 computers from this single switch. Rear cable connections help to eliminate cable tangles and minimize workspace disruption.
Backed by a StarTech.com 3-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Extracting the keyboard strokes from the USB connection this KVM enables hot key support for wireless keyboard and mouse combo kits that use a single USB receiver
- On Screen Display adds the ability to rename connected computers for easy identification and provides per-port password security
- Supports cascading with other KVM switches for one spot control of up to 136 computers
Design
Housing material
Steel
LED indicators
Y, Yes
Product colour
Black
Rack capacity
1U
Rack mounting
Yes
Display
Built-in display
No
Logistics data
Harmonized System (HS) code
85176200
Operational conditions
Operating relative humidity (H-H)
5 - 80 %
Operating temperature (T-T)
5 - 40 �C
Storage temperature (T-T)
-20 - 60 �C
Other features
Audio support
No
IP control
No
Package dimensions
Depth (package,cm)
46.8 cm
Gross Weight (Package, kg)
3 kg
Height (package,cm)
26.4 cm
Width (package,cm)
8.9 cm
Packaging content
AC adapter included
Yes
Manual
Yes
Performance
Daisy chain
Yes
Maximum resolution
1920 x 1440 Pixels
Plug and Play
Yes
Ports & interfaces
Audio connections
No
Console ports
USB A, VGA (D-Sub)
Console USB ports quantity
2
DC-in jack
Yes
Keyboard port type
USB
Mouse port type
USB
Number of computers controlled
16
Video port type
VGA
Power
AC input voltage
110-240 V
Input current
0.8 A
Output current
1.5 A
Output voltage
12 V
Power plug type
Type M
Product dimensions
Net Weight (Product, kg)
0.88 kg
Product Depth
18 cm
Product Height
4.5 cm
Product Width
54 cm
Vendor information
Brand Name
StarTech.com
Warranty
1 Year(s)
View AllClose
The SV1631DUSBU 16 Port 1U Rack Mountable USB KVM Switch with OSD lets you control 16 USB computers from a single console (USB keyboard, USB mouse, VGA monitor).
Convenient push-button and hot-key controls provide quick, reliable switching between connected computers while manual and auto-scan switching modes and an On Screen Display (OSD) offer additional control options.
Designed to ensure maximum space efficiency, the USB KVM switch features a slim 1U design that fits neatly into a server equipment rack/cabinet with the included brackets, and can be cascaded with multiple KVM switches to deliver control of up to 136 computers from this single switch. Rear cable connections help to eliminate cable tangles and minimize workspace disruption.
Backed by a StarTech.com 3-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Extracting the keyboard strokes from the USB connection this KVM enables hot key support for wireless keyboard and mouse combo kits that use a single USB receiver
- On Screen Display adds the ability to rename connected computers for easy identification and provides per-port password security
- Supports cascading with other KVM switches for one spot control of up to 136 computers
Design
Housing material
Steel
LED indicators
Y, Yes
Product colour
Black
Rack capacity
1U
Rack mounting
Yes
Display
Built-in display
No
Logistics data
Harmonized System (HS) code
85176200
Operational conditions
Operating relative humidity (H-H)
5 - 80 %
Operating temperature (T-T)
5 - 40 �C
Storage temperature (T-T)
-20 - 60 �C
Other features
Audio support
No
IP control
No
Package dimensions
Depth (package,cm)
46.8 cm
Gross Weight (Package, kg)
3 kg
Height (package,cm)
26.4 cm
Width (package,cm)
8.9 cm
Packaging content
AC adapter included
Yes
Manual
Yes
Performance
Daisy chain
Yes
Maximum resolution
1920 x 1440 Pixels
Plug and Play
Yes
Ports & interfaces
Audio connections
No
Console ports
USB A, VGA (D-Sub)
Console USB ports quantity
2
DC-in jack
Yes
Keyboard port type
USB
Mouse port type
USB
Number of computers controlled
16
Video port type
VGA
Power
AC input voltage
110-240 V
Input current
0.8 A
Output current
1.5 A
Output voltage
12 V
Power plug type
Type M
Product dimensions
Net Weight (Product, kg)
0.88 kg
Product Depth
18 cm
Product Height
4.5 cm
Product Width
54 cm
Vendor information
Brand Name
StarTech.com
Warranty
1 Year(s)
