Startech Sata Pcie Card 4 Port Pcie Sata Expansion Card 6Gbps Stacked Connectors 4P6G-PCIE-SATA-CARD

StarTech.com SATA PCIe Card, 4 Port PCIe SATA Expansion Card, 6Gbps, Stacked Connectors, Non-RAID, PCI Express to SATA Converter/Adapter - SATA III 6Gbps PCIe 3.0 x4 card - SATA expansion adapter card - 4-Port SATA to PCIe Card w/ASM1164 controller for 16Gbps combined max - PCI Express 3.0/SATA 3.2/AHCI 1.4 - ATA/ATAPI for HDD/SSD/ODD support - Windows/macOS/Linux - Full/low-profile This 4-port SATA III (6Gbps) controller enables you to add four SATA 6Gbps Hard Drives (HDDs) or Solid State Drives (SSDs) to your computer system or server via an available PCIe x4 card slot. The card supports SATA III and PCI-Express 3.0 Specifications. ASM1164 to Deliver 4-Port SATA 6Gbps Performance Featuring the ASM1164 controller, this SATA card enables the connection of four high-performance SATA 6Gbps drives with a combined total throughput of up to 16Gbps. The SATA drives are connected via four individual SATA ports located on the card (SATA cables sold separately). Wide Compatibility The controller card is widely supported across all popular operating system platforms including Windows (7, 8, 10), macOS (10.10 and above) and Linux (2.6.32 and above). The card also supports port multiplier, giving you the ability to connect multiple drives to a single SATA port (additional hardware required, sold separately). To further improve motherboard compatibility the card does not have a built-in RAID controller, but fully supports the use of software RAID. Plus, with support for PCIe 3.0 and SATA III Specifications this card ensures backward compatibility with previous generations (SATA I/II, PCIe 1/2) at lower performance. Hassle-Free Installation The SATA controller card features plug-and-play installation and can be installed in a full-profile or low-profile computer systems with the full-profile bracket preinstalled, and an interchangeable low-profile (half-height) bracket included. The card also supports storage software data management systems such as Storage Spaces (Microsoft) , RAID Assistant (MacOS) and mdraid/mdadm (Linux), for hassle-free setup, partitioning and software RAID array building. 4P6G-PCIE-SATA-CARD is backed by a StarTech.com 2-year warranty and free lifetime 24/5 North American based, multi-lingual support. More from the Manufacturer More from the Manufacturer
Interfaces/Ports

Total Number of SATA Ports4
Number of SATA Ports (Internal)4

Technical Information

Host InterfacePCI Express 3.0 x4
Device SupportedServer
Controller TypeSerial ATA/600
Operating System SupportedMac OS X 11.0 Big Sur
Linux 2.6.32
Mac OS X 10.10 Yosemite
Mac OS X 10.11 El Capitan
Mac OS X 10.12 Sierra
Mac OS X 10.13 High Sierra
Mac OS X 10.14 Mojave
Mac OS X 10.15 Catalina
Windows Server 2022
Mac OS X 12.0 Monterey
Mac OS X 13.0 Ventura
Windows 10
Windows 11
Windows 7
Windows 8
Windows 8.1
Windows Server 2012 R2
Windows Server 2019
Windows Server 2016
RAID SupportedNo


Miscellaneous

Platform SupportedPC
Linux
Mac

Physical Characteristics

Weight (Approximate)75 g
Form FactorPlug-in Card
Length71.1 mm
Height15.2 mm
Width55.9 mm

General Information

Product TypeSATA Controller
Manufacturer Part Number4P6G-PCIE-SATA-CARD
Manufacturer Website Addresshttp://www.startech.com/uk
ManufacturerStarTech.com
Product NamePCIe SATA Card
Brand NameStarTech.com
