Toshiba MK1002TSKB-RFB 1TB SATA Enterprise RAID MK1002TSKB-RFB

The Toshiba MKx001TRKB and MKx002TSKB series hard disk drives (HDDs) feature high storage capacities, enterprise-class reliability, enhanced power condition state technology, and performance efficiencies which are critical to business operations.
With a top storage capacity of 2TB*, the Toshiba MKx001TRKB and MKx002TSKB HDDs utilize a traditional 3.5-inch form factor, enabling system builders to leverage 3.5-inch based storage chassis. The high-capacity, cost-effective models feature 7,200 RPM spin speed and leading-edge 6Gb/sec Serial Attached SCSI (SAS) and 3Gb/sec Serial ATA (SATA) interfaces.
Both series leverage the expertise and history of Toshiba in enterprise-class storage and offer similar features as traditional enterprise-class drives including 24 x 7 operation, Error Correction (ECC), Rotational Vibration (RV) technology for multi-drive systems, 1.2 million hours MTBF, and a 5-year warranty.
The MKx001TRKB and MKx002TSKB series HDDs are designed to support enterprise applications where reliability, high capacity, and performance are required. Specific applications include SAN, NAS, DAS, cloud storage, data centers, entry level servers and tiered storage system architecture.

Features



Average latency



4.17 Millisecond


Average seek time



9.5 Millisecond


HDD capacity



1 TB


HDD size



3.5 "


HDD speed



7200 RPM


Hot-swap



No


Interface



Serial ATA


Mean time between failures (MTBF)



1200000 Hour


Storage drive buffer size



64 MB


Track to track seek time



1 Millisecond


Operational conditions



Non-operating shock



300 G


Non-operating vibration



5 G


Operating shock



70 G


Operating temperature (T-T)



5 - 55 �C


Operating vibration



0.75 G


Storage temperature (T-T)



-40 - 70 �C


Other features



Acoustic pressure emissions



34 dB


Data transfer rate



3 Gbit/s


Depth (imperial)



5.79 "


Dimensions (W x D x H) (imperial)



4 x 5.79 x 1.03 "


Dimensions (WxDxH)



101.6 x 147 x 26.1 mm


Height (imperial)



1.03 "


Internal



Yes


LED indicators



N, No


Mounting



Horizontal


Operating temperature (T-T)



41 - 131 �F


Output voltage



5 V


Product colour



Silver


Supported HDD interfaces



Serial ATA


Waterproof



No


Width (imperial)



4 "


Package dimensions



Depth (package,cm)



4.5 cm


Gross Weight (Package, kg)



0.74 kg


Height (package,cm)



13 cm


Width (package,cm)



18 cm


Power



Power consumption (idle)



7 Watt


Power consumption (read)



13 Watt


Power consumption (standby)



1.5 Watt


Power consumption (write)



13 Watt


Start-up current



2.4 A


Product dimensions



Net Weight (Product, kg)



0.64 kg


Product Depth



14.7 cm


Product Height



2.61 cm


Product Width



10.16 cm


Vendor information



Brand Name


Toshiba


Warranty



1 Year(s)
