TP-Link AC1200 Wireless VDSL/ADSL Modem Router ARCHERVR400

Superfast Wi-Fi - Up to 1.2Gbps
The Archer VR400 unlocks the full potential of your internet connection by providing combined dual band Wi-Fi speeds of up to 1.2Gbps, including 300Mbps on the 2.4GHz band and 867Mbps on the 5GHz band, eliminating lag and buffering from your online experience.

Two dedicated Wi-Fi networks support more devices and reduce wireless interference to create stable connections.

Superfast VDSL Broadband
The latest VDSL2 technology allows the Archer VR400 to deliver impressive VDSL broadband speeds of up to 100Mbps, which is almost five times faster than ADSL2+. The Archer VR400 serves as a DSL modem and wireless router, combining two devices in one. The integrated DSL port supports all standard DSL connections, including VDSL2, ADSL2+, ADSL2, and ADSL.

Versatile Backup Connectivity
With multiple inputs, the Archer VR400 provides you with a variety of options when connecting to the Internet. As a backup, the EWAN port allows the Archer VR400 to accept connections from cable and fiber modems via Ethernet cable. Additionally, the USB port supports 3G/4G dongle connections.

Superior Range and Stability
Three high-performance external antennas help the Archer VR400 create an expansive home network. Advanced Beamforming technology* automatically locates wireless devices and forms targeted, highly efficient wireless connections.

*Archer VR400 only supports Beamforming Technology at 5GHz band.

Blazing Fast Wired Performance
To help your wired devices achieve peak performance, the router’s Gigabit Ethernet ports operate 10x faster than standard Ethernet. Connecting an external drive to the USB 2.0 port allows you to share files, photos, music, and video with any device on the network.

Easy Setup and Use
Set up the Archer VR400 in minutes thanks to its intuitive web interface and the powerful Tether app. Tether also lets you manage its network settings from any Android or iOS device, including parental controls and media sharing.

Specs




WAN connection


Ethernet WAN




DSL WAN

Whether or not the product features a DSL WAN (Wide Area Network) connection option.




SIM card slot

Whether the device features a SIM card slot.




3G/4G USB modem compatibility




WAN connection type

RJ-45


Wireless LAN features


Wi-Fi band

The frequency bands the product features.

Dual-band (2.4 GHz / 5 GHz)


Top Wi-Fi standard

Connection of this device is done via Wi-Fi in a high standard.

Wi-Fi 5 (802.11ac)


WLAN data transfer rate (max)

867 Mbit/s


Wi-Fi standards

The type of wireless local area network (LAN). It can be ad-hoc, where units in a network communicate peer-to-peer, or Infrastructure, where units communicate with each other via an access point A LAN interconnects computers in a small area e.g. home, school or office.

802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)


WLAN data transfer rate (first band)

300 Mbit/s


WLAN data transfer rate (second band)

867 Mbit/s


Network


Ethernet LAN

An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.




Ethernet LAN interface type

The characteristics of the Ethernet LAN interface.

Gigabit Ethernet


Ethernet LAN data rates

The different speed levels of the Ethernet LAN connection.
, 100, 1000 Mbit/s


Cabling technology

Type of cable technology performance.
/100/1000Base-T(X)


Networking standards

The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.

IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n


Port forwarding




Dynamic DNS (DDNS)




Static route




VPN tunnels quantity



VPN Passthrough




VPN support

PTP, L2TP, IPSec Passthrough


DSL features


ADSL




ADSL2




ADSL2+




VDSL2




Ports & interfaces


Ethernet LAN (RJ-45) ports

Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.

5


USB port

The device features a socket into which a USB cable can be plugged.




USB 2.0 ports quantity

Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black.

1


Memory card slot(s)

Places where memory cards are placed inside and connected to the computer motherboard.




DC-in jack

The socket/plug where the DC electricity supply connects to the device.




Management features


Quality of Service (QoS) support




Reset button




WPS push button




Security


Security algorithms

Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product.

64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK


Firewall




Guest access




Access Control List (ACL)




Filtering




MAC address filtering

Security access control method whereby the 48-bit address assigned to each network card is used to determine access to the network. MAC addresses are uniquely assigned to each card, so using MAC filtering on a network permits and denies network access to specific devices through the use of blacklists and whitelists.





Security


DMZ support




Protocols


DHCP client

Whether the product features a DHCP (Dynamic Host Configuration Protocol) to obtain IP addresses within a network.




DHCP server

A server is a system which that responds to requests across a computer network to provide, or help to provide, a network service. DCHP servers uses the DCHP (Dynamic Host Configuration Protocol), which is a standardized networking protocol used by servers on an IP network to allocate IP addresses to computers. The purpose of DHCP is to automate the IP address configuration of a computer without a network administrator. IP addresses are typically selected from a range of assigned IP addresses stored in a database on the server and issued to a computer which requests a new IP address. An IP address is assigned to a computer for a set interval, after which, the computer must renew the IP address or acquire a new one.




Universal Plug and Play (UPnP)




Management protocols

SSL for TR-069, SNMP v1/2c, Web Based Firmware Upgrade, Diagnostic Tools


Supported network protocols

Network protocols tested as compatible with this product e.g. FTP,HTML, POP.

IPv4, IPv6


Design


Product colour

The colour e.g. red, blue, green, black, white.

Black


Wall mountable

The product can be mounted on (attached to ) a wall.




Indication light




LED indicators

LAN, Power, WLAN


On/off switch

The button which is pressed to switch the device on or off.




Product type

The sub-category of the product.

Tabletop router


Certificates


Certification

CE, RoHS


Packaging content


Cables included

LAN (RJ-45)


AC adapter included




Manual




Quick start guide

Instructions, either online, as a computer program or in paper form, to allow you to set up and start using the product quickly.




Antenna


Antenna design

External


Antennas quantity

3


Detachable antenna(s)




Power


Power source type

What the power source is.

AC


Output voltage
V


Output current

1.5 A


Operational conditions


Operating temperature (T-T)

The minimum and maximum temperatures at which the product can be safely operated.

0 - 40 °C


Storage temperature (T-T)

The minimum and maximum temperatures at which the product can be safely stored.

-40 - 70 °C


Operating relative humidity (H-H)
- 90%


Storage relative humidity (H-H)

5 - 90%


System requirements


Windows operating systems supported

Windows vesions wich can be used with the device.

Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64


Linux operating systems supported

8 RT. Linux (9.4, 9.5), Red Hat Enterprise Linux 5.0 (supported with a pre-built package); SUSE Linux (10.3, 11.0, 11, 11.1, 11.2), Fedora (9, 9.0, 10, 10.0, 11.0, 11, 12, 12.0), Ubuntu (8.04, 8.04.1, 8.04.2, 8.10, 9.04, 9.10, 10.04), Debian (5.0, 5.0.1, 5.0.2, 5.0.3)




Mac operating systems supported

Mac operating systems e.g. OS X can be used with the device.




Weight & dimensions


Width

The measurement or extent of something from side to side.

215.6 mm


Depth

The distance from the front to the back of something.
4.6 mm


Height

The measurement of the product from head to foot or from base to top.

31.6 mm


Packaging data


Package width

The distance from one side of the packaging to the other.

350 mm


Package depth

The distance from the front to the back of the packaging.

240 mm


Package height

The distance from the top to the bottom of the packaging.

82 mm


Package weight

Weight of the packaged product.

850 g


Package type

The type of product package e.g. box.

Box
