TP-Link Archer C50 Wireless Router Fast Ethernet Dual-Band 2.4 GHz / 5 GHz Black ARCHERC50

Fast Wireless Speed with 802.11ac
TP-LINK’s Archer C50 comes with the next generation Wi-Fi standard – 802.11ac, 3 times faster than wireless N speeds and delivering a combined wireless data transfer rate of up to 1.2Gbps. With 300Mbps over the 2.4GHz band and 867Mbps wireless speeds over the crystal clear 5GHz band, the Archer C50 is the superior choice for seamless HD streaming, online gaming and other bandwidth-intensive tasks.

1.2Gbps Dual Band Connections for Lag-Free Work and Entertainment
The Archer C50 operates over both the 2.4GHz and 5GHz bands, ensuring amazing wireless performance. Simultaneous Dual Band offers you the flexibility of two dedicated networks – with multiple times the bandwidth for your needs. Simple tasks like sending e-mails or web browsing can be handled by the 2.4GHz band while bandwidth intensive tasks like online gaming or HD video streaming can be processed by the 5GHz band – all at the same time.

2 External Antennas for Optimal Coverage
With 2 external antennas combined with high quality antenna technology, you can maintain high speeds across greater distances. This provides you with optimal wireless coverage and reliability from anywhere in your large home or office.

USB Port for Storage and Sharing
With USB 2.0 port, you can share a printer locally and files & media with networked devices or remotely via FTP server.

Specs




WAN connection


Ethernet WAN




DSL WAN

Whether or not the product features a DSL WAN (Wide Area Network) connection option.




SIM card slot

Whether the device features a SIM card slot.




3G/4G USB modem compatibility




WAN connection type

RJ-45


Wireless LAN features


Wi-Fi band

The frequency bands the product features.

Dual-band (2.4 GHz / 5 GHz)


Top Wi-Fi standard

Connection of this device is done via Wi-Fi in a high standard.

Wi-Fi 5 (802.11ac)


WLAN data transfer rate (max)

867 Mbit/s


Wi-Fi standards

The type of wireless local area network (LAN). It can be ad-hoc, where units in a network communicate peer-to-peer, or Infrastructure, where units communicate with each other via an access point A LAN interconnects computers in a small area e.g. home, school or office.

802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)


WLAN data transfer rate (first band)

300 Mbit/s


WLAN data transfer rate (second band)

867 Mbit/s


Network


Ethernet LAN

An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.




Ethernet LAN interface type

The characteristics of the Ethernet LAN interface.

Fast Ethernet


Ethernet LAN data rates

The different speed levels of the Ethernet LAN connection.
, 100 Mbit/s


Port forwarding




VPN support

PPTP, L2TP, IPSec


Receiver sensitivity

5GHz: 11a 54M: -77dBm 11ac VHT20 MCS8: -70dBm 11ac VHT40 MCS9: -66dBm 11ac VHT80 MCS9: -62dBm 2.4GHz: 11g 5.5M: -94dBm 11g 54M: -78dBm 11n HT20 MCS7: -75dBm 11n HT40 MCS7: -72dBm


Ports & interfaces


Ethernet LAN (RJ-45) ports

Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.

4


USB port

The device features a socket into which a USB cable can be plugged.




USB 2.0 ports quantity

Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black.

1


Management features


Quality of Service (QoS) support




Reset button




WPS push button




Security


Security algorithms

Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product.

64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK


Firewall




Stateful Packet Inspection (SPI)




DoS attack prevention




Filtering




MAC address filtering

Security access control method whereby the 48-bit address assigned to each network card is used to determine access to the network. MAC addresses are uniquely assigned to each card, so using MAC filtering on a network permits and denies network access to specific devices through the use of blacklists and whitelists.




IP address filtering




DMZ support





Protocols


DHCP client

Whether the product features a DHCP (Dynamic Host Configuration Protocol) to obtain IP addresses within a network.




DHCP server

A server is a system which that responds to requests across a computer network to provide, or help to provide, a network service. DCHP servers uses the DCHP (Dynamic Host Configuration Protocol), which is a standardized networking protocol used by servers on an IP network to allocate IP addresses to computers. The purpose of DHCP is to automate the IP address configuration of a computer without a network administrator. IP addresses are typically selected from a range of assigned IP addresses stored in a database on the server and issued to a computer which requests a new IP address. An IP address is assigned to a computer for a set interval, after which, the computer must renew the IP address or acquire a new one.




Universal Plug and Play (UPnP)




Design


Product colour

The colour e.g. red, blue, green, black, white.

Black


On/off switch

The button which is pressed to switch the device on or off.




Product type

The sub-category of the product.

Tabletop router


Packaging content


Cables included

LAN (RJ-45)


AC adapter included




Quick start guide

Instructions, either online, as a computer program or in paper form, to allow you to set up and start using the product quickly.




Antenna


Antenna design

External


Antennas quantity

2


Features


Built-in processor

Whether or not a processor is built into the device.




Processor cores

The number of central processing units ('cores') in a processor. Some processors have 1 core, others have 2 (e.g. Intel Core Duo) or more (e.g. the Intel Xeon E7-2850 has 10 cores).

1


Power


Power source type

What the power source is.

AC


Output voltage

9 V


Output current

0.85 A


Operational conditions


Operating temperature (T-T)

The minimum and maximum temperatures at which the product can be safely operated.

0 - 40 °C


Storage temperature (T-T)

The minimum and maximum temperatures at which the product can be safely stored.

-40 - 70 °C


Operating relative humidity (H-H)
- 90%


Storage relative humidity (H-H)

5 - 90%


Weight & dimensions


Width

The measurement or extent of something from side to side.
2.9 mm


Depth

The distance from the front to the back of something.
3.5 mm


Height

The measurement of the product from head to foot or from base to top.

32.1 mm


Packaging data


Package width

The distance from one side of the packaging to the other.

290 mm


Package depth

The distance from the front to the back of the packaging.

240 mm


Package height

The distance from the top to the bottom of the packaging.

76 mm


Package weight

Weight of the packaged product.

670 g


Logistics data


Harmonized System (HS) code

85176990
