TP-Link AV2000 2-Port Gigabit Passthrough Powerline Starter Kit TL-PA9020PKIT

Internet For A Brighter Life
AV2000 Gigabit Passthrough Powerline Starter Kit
TL-PA9020P KIT

Take Your Powerline Network to the Next Level
With advanced HomePlug AV2 MIMO, the TL-PA9020p delivers high speed of up to 2000Mbps over Powerline to provide superior network performance that supports all of your online needs. With a lag-free connection, you will never miss out again.

An Exclusive Fast Lane for Your Favorite Devices
The TL-PA9020p creates fast, high performance wired connections that support all of your favorite devices, like 4K HDTV. Now you can plug in to enjoy an exclusive fast lane out of a
crowded network without slowing down.

Fluid Streaming and Gaming with 2X2 MIMO
2X2 MIMO with Beamforming Technology significantly improves speeds,
especially during peak hours.

More Stable Connections
2X2 MIMO is like adding extra lanes to a highway. It establishes multiple simultaneous connection for you to enjoy higher speeds and greater stability.

Enhanced Long Distance Performance
2X2 MIMO with Beamforming Technology also offers the benefit of improved coverage throughout the home, particularly for previously hard to reach outlets.

Wiring up with Gigabit Speeds
Connect to Gigabit speeds for your smart TVs, game consoles, computers and
network attached storage devices. Just use an Ethernet cable to attach your devices
to the Powerline adapter to get started!

Simplified Network for a Better Life
Plug, Pair and Play!

1. First, connect your TL-PA9020P to the router
2. Then, plug in another one wherever you need extra coverage
3. Finally, press the “Pair” button on each adapter
Congratulations! You are ready to enjoying seamless wired connections.

No Power Outlet
is Going to Waste
The integrated power socket means that you can still get power from the outlet for your other devices. Simply plug your device into the integrated socket the same way you would with a normal wall outlet. The built-in noise filter also helps to eliminate electrical signal noise that might otherwise affect powerline transmission performance.

Specs




Performance


Maximum data transfer rate

The maximum speed with which data can be transmitted from one device to another.
00 Mbit/s


Ethernet LAN

An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.




Ethernet LAN interface type

The characteristics of the Ethernet LAN interface.

Gigabit Ethernet


Ethernet LAN data rates

The different speed levels of the Ethernet LAN connection.
, 100, 1000 Mbit/s


Ethernet LAN (RJ-45) ports

Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.

2


Networking standards

The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.

IEEE 1901, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u


Built-in power socket

There is a power socket (port) in the device.




PowerLine standard

Power-line communication (PLC) carries data on a conductor that is also used simultaneously for AC electric power transmission or electric power distribution to consumers. Two distinctly different sets of standards apply to powerline networking as of early 2010. Within homes, the HomePlug AV and IEEE 1901 standards specify how, globally, existing AC wires should be employed for data purposes. The IEEE 1901 includes HomePlug AV as a baseline technology, so any IEEE 1901 products are fully interoperable with HomePlug AV, HomePlug GreenPHY or HomePlug AV2 specification.

HomePlug AV2


Modulation

Modulation is the process of varying one or more properties of a periodic waveform, called the carrier signal (High Frequency Signal), with a modulating signal which typically contains information to be transmitted. The aim of digital modulation is to transfer a digital bit stream over an analog bandpass channel, for example over the public switched telephone network (where a bandpass filter limits the frequency range to between 300 and 3400 Hz), or over a limited radio frequency band. The aim of analog modulation is to transfer an analog baseband (or lowpass) signal, for example an audio signal or TV signal, over an analog bandpass channel at a different frequency, for example over a limited radio frequency band or a cable TV network channel.

OFDM


Security algorithms

Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product.
8-bit AES


Maximum operating distance

The maximum distance from which you can operate the device.

300 m


Plug and Play

Indicates whether this product supports is "plug and play". Plug and play is hardware or software that, after being installed ("plugged in"), can immediately be used ("played with"), as opposed to hardware or software which requires configuration.




Power


Power consumption (typical)

Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.

5.8 W


Power consumption (standby)

The amount of electricity that is consumed when the product is on standby.

0.5 W


AC input voltage

The voltage of the AC electricity that is inputted into the product.

230 V


AC input frequency

50 Hz


Current
A


Design


Antenna type

Type of antenna, also known an aerial, e.g. external, internal.

Internal


LED indicators

LAN, Power


Product colour

The colour e.g. red, blue, green, black, white.

White


Certification

CE


System requirements


Windows operating systems supported

Windows vesions wich can be used with the device.

Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home



System requirements


Linux operating systems supported

8 RT. Linux (9.4, 9.5), Red Hat Enterprise Linux 5.0 (supported with a pre-built package); SUSE Linux (10.3, 11.0, 11, 11.1, 11.2), Fedora (9, 9.0, 10, 10.0, 11.0, 11, 12, 12.0), Ubuntu (8.04, 8.04.1, 8.04.2, 8.10, 9.04, 9.10, 10.04), Debian (5.0, 5.0.1, 5.0.2, 5.0.3)




Mac compatibility

Product can be used with Apple Mac software and/or hardware.




Mac operating systems supported

Mac operating systems e.g. OS X can be used with the device.

macOS


Operational conditions


Operating temperature (T-T)

The minimum and maximum temperatures at which the product can be safely operated.

0 - 40 °C


Storage temperature (T-T)

The minimum and maximum temperatures at which the product can be safely stored.

-40 - 70 °C


Operating relative humidity (H-H)
- 90%


Storage relative humidity (H-H)

5 - 90%


Weight & dimensions


Width

The measurement or extent of something from side to side.
0.7 mm


Depth

The distance from the front to the back of something.

71.7 mm


Height

The measurement of the product from head to foot or from base to top.

66.3 mm


Certificates


Compliance certificates

RoHS


Packaging data


Package width

The distance from one side of the packaging to the other.

230 mm


Package depth

The distance from the front to the back of the packaging.
0 mm


Package height

The distance from the top to the bottom of the packaging.
0 mm


Package weight

Weight of the packaged product.

780 g


Packaging content


Quantity per pack

2 pc(s)


Quick installation guide




Cables included

LAN (RJ-45)


Logistics data


Harmonized System (HS) code

85171800
