Tp-Link Insight S345-4G Vigi 4Mp Outdoor Full-Colour 4G Bullet Network Camera W/ INSIGHT S345-4G(4MM)

VIGI 4MP Outdoor Full-Color 4G Bullet Network Camera

4MP Super-High Definition and 24h Full-Color
4G Mobile Networking*
3 LAN Ports for Downstream Devices
Human & Vehicle Classification
Smart Detection
Smart Video Enhancement Technology
Active Defense and Two-Way Audio
H.265+ Compression Technology
IP66 Weatherproof

*MicroSD card and Nano-SIM card are not included

3 LAN Ports Meet Minimal Deployment Effort

InSight S345-4G offers industry-first three LAN ports, enabling simultaneous connectivity for up to three devices as you need. It is ideal for coupling with solar power systems to eliminate additional wiring deployments.

Human & Vehicle Classification
Distinguish humans and vehicles from other objects and receive more accurate event notifications. Learn more about VIGI AI technology >> LightPro Night Vision Technology

The VIGI LightPro Night Vision Technology intelligently switches between IR night vision and full-color night vision by detecting people or vehicles. This allows the camera to capture clearer and more critical details with the white light on, and to reduce light pollution and energy consumption with the IR light on at most time, effectively adapting to a broader range of scenarios.

More Details
Less Light Pollution
More Deterrence
More Concealment Smart Video Enhancement Technology

True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.
Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.
3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.
White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.
Efficient H.265+ Compression Technology
H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.

DescriptionSpecification

#Hide#Form Factor: Bullet
Suitable for Outdoor: Yes
Wired/Wireless: Wired/Wireless
Interface(s): 3 x RJ45 10/100M LAN Ports
DC Power Port
Memory Card Slot (MicroSD Card up to 512GB)
Built-in Nano-SIM Card Slot
Image Sensor: 1/2.7” Progressive Scan CMOS
Resolution: "Main Stream:
2688x1520, 2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720

Sub-Stream:
848x480, 704x576, 640x480, 640x360, 352x288, 320x240"
Frame Rate: "Main Stream:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

Sub-Stream:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps"
Video Compression: Main Stream:
H.265+/H.265/H.264+/H.264

Sub-Stream:
H.265/H.264
Lens: 4mm Fixed Focal Lens
Lens Mount: M12
Aperture: F1.6

DORI Distance:
Detect: 80 m (262 ft)
Observe: 33 m (109 ft)
Recognize: 16 m (52 ft)
Identify: 8 m (26 ft)
Viewing Angle: Horizontal FOV: 80.4°
Vertical FOV: 41.8°
Diagonal FOV: 98.7°
Pan/Tilt/Rotation: Pan: 0° to 360°
Tilt: 0° to 90°
Rotation: 0° to 360°
Day/Night Mechanism: IR Cut Filter
Day/Night Switch: Unified/ Scheduled/ Auto
IR Working Distance: IR LED Quantity: 2
Range: 50m
Wavelength: 850nm
Minimum Illumination: "0.005 Lux; 0 Lux with IR/White Light"
Video Streaming: Main Stream
Sub-Stream
Image Settings: Mirror
Brightness
Contrast
Saturation
Sharpness
Exposure
WDR
White Balance
Prevent Overexposure to Infrared Light
Audio Features: Two-Way Audio
Built-in Microphone
Built-in Speaker
Audio Compression
Audio Sampling Rate: 8KHz
Environment Noise Filtering
Audio Bit Rate: 64 Kbps(G.711 alaw)
Alarm & Event Management: "Smart Event Detection:
Intrusion, Line-Crossing, Region Entering, Region Exiting, Object Abandoned, Object Removal, Loitering, People, Vehicle, Abnormal Sound, Scene Change

Basic Event:
Motion
Video Tampering
Exception (Illegal Login)

Alarm Linkage:
Memory Card Video Recording, Message Push, Audible Warning, White Light Flashing, Upload to FTP, Send to Alarm Server, Email Alarm"
Network: "Protocol: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP

ONVIF: Yes

API: Open Network Video Interface (Profile S/G/T)

Simultaneous Live View: 3 Main Streams & 3 Sub-Streams

Cloud: Yes"
Wireless Features: "4G:
Standard: LTE-TDD/LTE-FDD/WCDMA
Nano SIM
Category: 4
Uplink: 50 Mbps, Downlink: 150 Mbps"
Security: "Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication"
Management: "VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS, VIGI Config Tool, VIGI PC Client"
Power Supply: "12V DC/1 A, 5.5 mm Coaxial Power Plug"
Additional Features: See Overview
Weight/Dimensions: 1.09 kg
(LxWxH) 256 x 122 x 101 mm (excluding antennas)
Environment: IP66 Waterproof
Operating Temperature: -30–60 °C
Storage Temperature: -40–60 °C
Operating Humidity: 95% or Less (Non-Condensing)
Storage Humidity: 95% or Less (Non-Condensing)
Package Contents: VIGI Network Camera
Quick Start Guide
Waterproof Cable Attachments
Mounting Accessories
Power Adapter
Package Weight: 1.5800 kg
Warranty: 5 Years
#Hide#Resolution: 4MP
