TP-Link INSIGHT S445ZI CCTV security camera Outdoor Wired 207 m 120 dB Ceiling INSIGHT S445ZI
(No reviews yet)
Write a Review
- UPC:
- 1210002606318
- MPN:
- INSIGHT S445ZI
- Condition:
- New
- Availability:
- Available with FREE Delivery (usually delivered within 5-7 working days)
Description
Motorized Varifocal
By adjusting the field of view (FOV), this feature assists you in concentrating on areas of interest, minimizing invalid detection zones, and enhancing target clarity.
Human & Vehicle Classification
Distinguish humans and vehicles from other objects and receive more accurate event notifications.
True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.
Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.
3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.
White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.
Efficient H.265+ Compression Technology
H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.
Features
5X Optical Zoom for Easy Installation and Monitoring
4MP Super-High Definition and IR Range Up to 60m (197ft)
Human & Vehicle Classification
Smart Detection
Smart Video Enhancement Technology
Audio and Alarm Interface Available
IP67 Weatherproof and IK10 Vandal Proof
H.265+ Compression Technology
Lens system
Recognize distance
41 m
Focal length range
2.7 - 13.5 mm
Fixed focus
No
Focus
Motorized
Optical zoom
5x
Identify distance
21 m
Auto focus
Yes
Maximum aperture number
1.6
Detect distance
7 m
Observe distance
86 m
Night vision
Night vision
Yes
LED type
IR/White
Security
Motion sensor
Yes
Video motion detection
Yes
Built-in siren
Yes
Mirror
Yes
Alert notification type
Push notification
Human and vehicle targets classification
Yes
Password protection
Yes
IP address filtering
Yes
HTTPS encryption
Yes
Digest authentication
Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports
1
DC-in jack
Yes
Management features
Reset button
Yes
Web browser
Yes
Cloud-managed
Yes
Design
International Protection (IP) code
IP67
Product colour
White
Weatherproof
Yes
Mounting type
Ceiling
Housing material
Metal
Protection features
Waterproof
Form factor
Turret
Storage
Compatible memory cards
MicroSD (TransFlash)
Maximum memory card size
512 GB
Weight & dimensions
Length
2.3 mm
Height
92.5 mm
Width
2.3 mm
Weight
710 g
Packaging content
Mounting kit
Yes
Drilling template included
Yes
Manual
Yes
Screws included
Yes
Number of cameras
1
Video
Highlight Compensation (HLC)
Yes
Bit rate control
Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Maximum resolution
2688 x 1520 pixels
Bit rate
Main Stream: 256 Kbps to 6 Mbps, Sub-Stream: 512 Kbps to 1024 Kbps
Video compression formats
H.264, H.264+, H.265, H.265+
Back Light Compensation (BLC)
Yes
Digital Wide Dynamic Range (DWDR)
Yes
Total megapixels
4 MP
Video recording
Yes
Supported graphics resolutions
20 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 2688 x 1520
Image quality adjustment
Brightness, Contrast, Mirror, Saturation, Sharpness
Network
Bluetooth
No
Supported network protocols
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
Wi-Fi
No
Live view
Yes
Ethernet LAN
Yes
Networking standards
IEEE 802.3af, IEEE 802.3at
Camera
Lens viewing angle, vertical
.8-53.8
Lens viewing angle, horizontal
29.6-102.0
Camera shutter speed
1/3 to 1/10000
Lens viewing angle, diagonal
34.1-122.8
Tilt angle range
0 - 90
Minimum illumination
0 lx
Operational conditions
Operating temperature (T-T)
-30 - 60 C
Operating relative humidity (H-H)
0 - 95
Storage relative humidity (H-H)
0 - 95
Storage temperature (T-T)
-40 - 60 C
Performance
Infrared (IR) cut-off filter
Yes
Maximum operating distance
7 m
Day/night mode
Yes
Placement supported
Outdoor
Wide Dynamic Range (WDR)
Yes
Dynamic range
0 dB
Remote viewing
Yes
Connectivity technology
Wired
Type
IP security camera
Image sensor
Optical sensor size
25.4 / 2.9 mm (1 / 2.9")
Sensor type
CMOS
Progressive scan
Yes
Audio
Bit rate range
0 - 64 Kbit/s
Audio system
2-way
Built-in microphone
Yes
Sample rate
8 kHz
Audio input channels
1 channels
Audio formats supported
G.711 A-law
Built-in speaker(s)
Yes
Number of microphones
1
Audio output channels
1 channels
Power
Power consumption (Power over Ethernet (PoE))
W
Power source type
DC, PoE
DC output voltage
Power consumption (max)
.8 W
Packaging data
Package type
Box
Package weight
960 g
View AllClose
By adjusting the field of view (FOV), this feature assists you in concentrating on areas of interest, minimizing invalid detection zones, and enhancing target clarity.
Human & Vehicle Classification
Distinguish humans and vehicles from other objects and receive more accurate event notifications.
True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.
Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.
3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.
White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.
Efficient H.265+ Compression Technology
H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.
Features
5X Optical Zoom for Easy Installation and Monitoring
4MP Super-High Definition and IR Range Up to 60m (197ft)
Human & Vehicle Classification
Smart Detection
Smart Video Enhancement Technology
Audio and Alarm Interface Available
IP67 Weatherproof and IK10 Vandal Proof
H.265+ Compression Technology
Lens system
Recognize distance
41 m
Focal length range
2.7 - 13.5 mm
Fixed focus
No
Focus
Motorized
Optical zoom
5x
Identify distance
21 m
Auto focus
Yes
Maximum aperture number
1.6
Detect distance
7 m
Observe distance
86 m
Night vision
Night vision
Yes
LED type
IR/White
Security
Motion sensor
Yes
Video motion detection
Yes
Built-in siren
Yes
Mirror
Yes
Alert notification type
Push notification
Human and vehicle targets classification
Yes
Password protection
Yes
IP address filtering
Yes
HTTPS encryption
Yes
Digest authentication
Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports
1
DC-in jack
Yes
Management features
Reset button
Yes
Web browser
Yes
Cloud-managed
Yes
Design
International Protection (IP) code
IP67
Product colour
White
Weatherproof
Yes
Mounting type
Ceiling
Housing material
Metal
Protection features
Waterproof
Form factor
Turret
Storage
Compatible memory cards
MicroSD (TransFlash)
Maximum memory card size
512 GB
Weight & dimensions
Length
2.3 mm
Height
92.5 mm
Width
2.3 mm
Weight
710 g
Packaging content
Mounting kit
Yes
Drilling template included
Yes
Manual
Yes
Screws included
Yes
Number of cameras
1
Video
Highlight Compensation (HLC)
Yes
Bit rate control
Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Maximum resolution
2688 x 1520 pixels
Bit rate
Main Stream: 256 Kbps to 6 Mbps, Sub-Stream: 512 Kbps to 1024 Kbps
Video compression formats
H.264, H.264+, H.265, H.265+
Back Light Compensation (BLC)
Yes
Digital Wide Dynamic Range (DWDR)
Yes
Total megapixels
4 MP
Video recording
Yes
Supported graphics resolutions
20 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 2688 x 1520
Image quality adjustment
Brightness, Contrast, Mirror, Saturation, Sharpness
Network
Bluetooth
No
Supported network protocols
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
Wi-Fi
No
Live view
Yes
Ethernet LAN
Yes
Networking standards
IEEE 802.3af, IEEE 802.3at
Camera
Lens viewing angle, vertical
.8-53.8
Lens viewing angle, horizontal
29.6-102.0
Camera shutter speed
1/3 to 1/10000
Lens viewing angle, diagonal
34.1-122.8
Tilt angle range
0 - 90
Minimum illumination
0 lx
Operational conditions
Operating temperature (T-T)
-30 - 60 C
Operating relative humidity (H-H)
0 - 95
Storage relative humidity (H-H)
0 - 95
Storage temperature (T-T)
-40 - 60 C
Performance
Infrared (IR) cut-off filter
Yes
Maximum operating distance
7 m
Day/night mode
Yes
Placement supported
Outdoor
Wide Dynamic Range (WDR)
Yes
Dynamic range
0 dB
Remote viewing
Yes
Connectivity technology
Wired
Type
IP security camera
Image sensor
Optical sensor size
25.4 / 2.9 mm (1 / 2.9")
Sensor type
CMOS
Progressive scan
Yes
Audio
Bit rate range
0 - 64 Kbit/s
Audio system
2-way
Built-in microphone
Yes
Sample rate
8 kHz
Audio input channels
1 channels
Audio formats supported
G.711 A-law
Built-in speaker(s)
Yes
Number of microphones
1
Audio output channels
1 channels
Power
Power consumption (Power over Ethernet (PoE))
W
Power source type
DC, PoE
DC output voltage
Power consumption (max)
.8 W
Packaging data
Package type
Box
Package weight
960 g
