TP-Link Omada 10G Multi-Gigabit SFP Media Converter MC420L

What This Product Does
The MC420L is a media converter designed to convert between 10GBASE-SR/LR fiber, 10GBASE-LRM fiber and 10GBASE-T copper media. It easily extends the distance of an existing gigabit network via fiber optic when integrated with the SFP Module. The MC420L applies the IEEE 802.3ae 10GBASE-SR/LR 10G Ethernet & IEEE 802.3an 10GBASE-T 10G Ethernet standards as part of its intended use with multi-mode/single-mode SFP Module. Long-range point-to-point connections are easily built with the gigabit fiber converters, making them ideal for network connections across multiple buildings, for remote surveillance and automated factory equipment.

MC420L offers flexible installation on standalone desktops or inserted into a chassis (TP-Link's MC1400). The easy-to-view front panel status LEDs provide real-time status information to monitor up-to-the-minute network activity. While the maximum transmission distance of fiber optics depends on the insertion of the SFP module.

Specs




Network


Maximum data transfer rate

The maximum speed with which data can be transmitted from one device to another.
000 Mbit/s


Networking standards

The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.

IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3aq, IEEE 802.3x, IEEE 802.3z


Copper ethernet cabling technology

2.5GBASE-T, 10GBASE-T, 1000BASE-T


Data transfer rate

Rate at which data can be transferred, usually measured in units per second. May vary with network configurations.
000 Mbit/s


Auto-negotiation




Duplex system

A duplex communication system is a point-to-point system composed of two connected parties or devices that can communicate with one another in both directions, simultaneously.

Full, Half


Performance


Maximum transfer distance

The greatest distance over which the data/signal can be transferred.
0 m


Fiber mode structure

Multi-mode, Single-mode


Features


Internal

The product is built in.




LED indicators

Activity, Link, Power


Product colour

The colour e.g. red, blue, green, black, white.

Black


Ports & interfaces


Connectivity technology

The technology that enables connectivity of the device, e.g. wired or wireless.

Wired


Ethernet LAN (RJ-45) ports

Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.

1


Fiber ports quantity

The number of sockets (ports) for fibers (cables).

1



Ports & interfaces


Fiber optic connector

This terminates the end of an optical fiber, and enables quicker connection and disconnection than splicing. The connectors mechanically couple and align the cores of fibers so light can pass. Better connectors lose very little light due to reflection or misalignment of the fibers. In all there have been about 100 types of optic fiber connectors produced.

SFP+


Power


Power consumption (max)

The maximum amount of power used by the device.

4.12 W


Weight & dimensions


Width

The measurement or extent of something from side to side.

94.5 mm


Depth

The distance from the front to the back of something.

73 mm


Height

The measurement of the product from head to foot or from base to top.

27 mm


Operational conditions


Operating temperature (T-T)

The minimum and maximum temperatures at which the product can be safely operated.

0 - 50 °C


Storage temperature (T-T)

The minimum and maximum temperatures at which the product can be safely stored.

-40 - 70 °C


Operating relative humidity (H-H)
- 90%


Storage relative humidity (H-H)

5 - 90%


Packaging content


AC adapter included




Manual




Certificates


Compliance certificates

RoHS, UL
