TP-Link RE450 Network Extender Network Transmitter White 10 100 1000 Mbit/s RE450

Boost Your Wi-Fi Coverage Up to 10,000 sq ft*
Tired of Wi-Fi “dead zones”? The TP-Link AC1750 Wi-Fi Range Extender connects to your router wirelessly, strengthening and expanding its signal into areas it can’t reach on its own. The device also reduces signal interference to ensure reliable Wi-Fi coverage throughout your home or office.

Super-Fast Speed Next Generation AC Wi-Fi
TP-Link's RE450 comes with next generation 802.11AC Wi-Fi technology, it's 3 times faster than the standard 802.11n speeds. The RE450 delivers fast speeds of dual band Wi-Fi up to 1.75Gbps, providing reliable connections for bandwidth-intensive tasks like HD/4K streaming, lag free gaming, large file downloads.

Gigabit Wired Speed
A gigabit Ethernet port turns the extender into a wireless bridge, letting you connect a wired device like a Blu-ray player, gaming console, DVR, or smart TV to your Wi-Fi network.

Easy Installation & Quick Position
Easy Installation with RE Button
The extender RE450 works with any standard wireless router. Instantly connect the RE450 to a router by pressing the extender’s RE button followed by the router’s WPS button (if available).

Once connected with an existing router, you can take RE450 anywhere within the wireless range of the existing router, no more further configurations.

Specs




Performance


Type

Characteristics of the device.

Network transmitter


Data transfer rate

Rate at which data can be transferred, usually measured in units per second. May vary with network configurations.
50 Mbit/s


Ethernet LAN data rates

The different speed levels of the Ethernet LAN connection.
, 100, 1000 Mbit/s


WPS push button




Windows operating systems supported

Windows vesions wich can be used with the device.




Mac operating systems supported

Mac operating systems e.g. OS X can be used with the device.




Linux operating systems supported

8 RT. Linux (9.4, 9.5), Red Hat Enterprise Linux 5.0 (supported with a pre-built package); SUSE Linux (10.3, 11.0, 11, 11.1, 11.2), Fedora (9, 9.0, 10, 10.0, 11.0, 11, 12, 12.0), Ubuntu (8.04, 8.04.1, 8.04.2, 8.10, 9.04, 9.10, 10.04), Debian (5.0, 5.0.1, 5.0.2, 5.0.3)




Antenna


Antennas quantity

3


Antenna type

Type of antenna, also known an aerial, e.g. external, internal.

External


Network


Cabling technology

Type of cable technology performance.
/100/1000Base-T(X)


Networking standards

The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.

IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u


Wi-Fi

Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.




Wi-Fi standards

The type of wireless local area network (LAN). It can be ad-hoc, where units in a network communicate peer-to-peer, or Infrastructure, where units communicate with each other via an access point A LAN interconnects computers in a small area e.g. home, school or office.

802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)


Wi-Fi data rate (max)
50 Mbit/s


Wi-Fi band

The frequency bands the product features.

Dual-band (2.4 GHz / 5 GHz)


Security algorithms

Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product.

64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK, WPS


SSID Broadcast




Web-based management

Using a website/web application to manage something.




Ports & interfaces


Ethernet LAN (RJ-45) ports

Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.

1


Design


Product colour

The colour e.g. red, blue, green, black, white.

White


LED indicators





Design


On/off switch

The button which is pressed to switch the device on or off.




Reset button




Certification

CE, FCC


Power


Power consumption (max)

The maximum amount of power used by the device.

9 W


Operational conditions


Operating temperature (T-T)

The minimum and maximum temperatures at which the product can be safely operated.

0 - 30 °C


Storage temperature (T-T)

The minimum and maximum temperatures at which the product can be safely stored.

-40 - 70 °C


Operating relative humidity (H-H)
- 90%


Storage relative humidity (H-H)

5 - 90%


Weight & dimensions


Width

The measurement or extent of something from side to side.

76.4 mm


Depth

The distance from the front to the back of something.

66.5 mm


Height

The measurement of the product from head to foot or from base to top.
3 mm


Packaging content


Cables included

LAN (RJ-45)


Quick start guide

Instructions, either online, as a computer program or in paper form, to allow you to set up and start using the product quickly.




Packaging data


Package width

The distance from one side of the packaging to the other.
2 mm


Package depth

The distance from the front to the back of the packaging.
5 mm


Package height

The distance from the top to the bottom of the packaging.

86 mm


Certificates


Compliance certificates

RoHS


Logistics data


Harmonized System (HS) code

85176990
