V7 DOCKTB4PT. Connectivity Technology: Wired Host Interface: Thunderbolt 4 Headp DOCKTB4PT

V7 DOCKTB4PT. Connectivity technology: Wired, Host interface: Thunderbolt 4, Headphone connectivity: 3.5 mm. Product colour: Black, Silver, Compatible memory cards: MicroSD (TransFlash), SD, Data transfer rate: 2.5 Gbit/s. Power source type: DC, AC input voltage: 100 - 240 V, Output voltage: 20 V. Width: 85 mm, Depth: 225 mm, Height: 22 mm. Quantity per pack: 1 pc(s), Package width: 160 mm, Package depth: 270 mm This DOCKTB4PT Thunderbolt 4 Triple Alt Mode Display Docking Station from V7 adds up to 3 displays, 3 USB ports, 2 Thunderbolt 4 ports, a USB-C port with up to 96 Watts Power Delivery, Audio, SD/Micro SD Memory Cards and up to 2.5 Gigabit Ethernet network connectivity to your Thunderbolt 4 enabled computer while charging at the same time with up to 96W power delivery. It features two HDMI ports and two DisplayPort outputs that can be used to extend or mirror your device for multitasking productivity. It supports single 8K 30Hz display (HDMI or DP) or up to three 4K (4K/60Hz + 4K/60Hz + 4K/30Hz) displays. It is Thunderbolt 4 certified and compatible with DisplayPort Alt mode and USB4 enabled computers and mobile devices. It includes both K-Lock and N-Lock interface for security. This solution provides high performance connectivity to extend and enhance your workstation productivity with a 2 year warranty. 150 Watt Power Supply included.
Network & Communication

Ethernet TechnologyGigabit Ethernet

Power Description

Maximum Power Supply Wattage150 W

Software

Operating System SupportedLinux
ChromeOS
Windows
macOS
Android

Physical Characteristics

Weight (Approximate)499 g
Length225 mm
Height22 mm
Width85 mm
Product ColorBlack
Silver
Color FamilyDual Colour

General Information

Product TypeDocking Station
Manufacturer Part NumberDOCKTB4PT
Manufacturer Website Addresshttp://www.v7world.com
Packaged Quantity1
ManufacturerV7
Product ModelDOCKTB4PT
Product NameDOCKTB4PTThunderboltÔäó 4 Triple Alt Mode Display Docking Station
Brand NameV7

Miscellaneous

Additional InformationAudio Channel: 384KHz sampling rate
Compliance: CE,FCC
Docking Type: Alt Mode
Material: ABS
Operating Temperature: 0Ôäâ to +45Ôäâ
Output Voltage: 20V/7.5A DC
Package Dimensions (L/W/H): 10.63 x 6.3 x 2.36 in
Shipping Weight: 2.31 lbs
Storage Temperature: 0Ôäâ to +70Ôäâ
USB Display Type: Alt-Mode

Country of OriginVietnam
Environmentally FriendlyYes
Brand CompatibilityHP
Lenovo
Microsoft
Samsung
Sony
Acer
Apple
Asus
Dell
Kensington Security SlotYes
Environmental ComplianceRestriction of Hazardous Substances (RoHS)


Interfaces/Ports

Host InterfaceThunderbolt 4
HDMIYes
HDMI Version2
Number of HDMI Ports2
Network (RJ-45)Yes
Number of HDMI Outputs2
Total Number of USB Ports6
ThunderboltYes
Headphone/Microphone Combo PortYes
Number of RJ-45 Ports1
USB Type-CYes
USB Type-C Detail1 x USB-C 3.2 Gen2
Thunderbolt Ports Quantity2
USB Power Delivery96W
Number of USB 3.2 Gen 1 Type-A Ports1
Number of USB 3.2 Gen 2 Type-A Ports2
Number of Thunderbolt 4 Ports3
USB Type-AYes

Technical Information

Connectivity TechnologyWired
FeaturesSecurity Lock
Charging CapabilityYes
Memory Card SupportedSD
microSD
Memory Card ReaderYes
Maximum Data Transfer Rate320 MB/s
Number of Displays Supported3
Supported Resolutions3840 x 2160
7680 x 4320
2560 x 1440 20 x 1080
Screen Mode Supported2K
4K
8K
Full HD
Security Slot TypeNoble Wedge Security Slot
Kensington Security Slot
