Viewsonic 86" 4K Professional Commercial Display With Proav Integration. Product CDE8631-1C

Viewsonic 86" 4K Professional Commercial Display with ProAV Integration. Product design: Digital signage flat panel. Display diagonal: 2.18 m (86"), Display technology: LCD, Display resolution: 3840 x 2160 pixels, Display brightness: 500 cd/m??, HD type: 4K Ultra HD. Wi-Fi. Operating hours (hours/days): 24/7. Operating system installed: Android 14. Product colour: Black The ViewSonic CDE31 Series is a turnkey, commercial-grade digital display that delivers impactful communication across corporate, retail, education, and healthcare environments. With native 4K Ultra HD resolution and reliable 24/7 operation, it delivers sharp, consistent visuals in both landscape and portrait orientations??� ideal for digital signage and meeting spaces. Powered by Android 14 OS and a next-generation Quad-Core SoC with 8GB RAM, the CDE31 Series ensures smooth playback and responsive performance for continuous content delivery. The platform is upgradeable to Android 16, supporting ongoing security updates and long-term compatibility. For streamlined deployment and management, it offers seamless ProAV integration with leading control systems, dual 16W built-in speakers, 3.5 mm audio in/out. It also supports static IP configuration, a simplified web-based UI, and centralized remote control via ViewSonic Manager. Always-On Playback ??? Fast Warm Boot for Seamless Communication With a warm boot in under 7 seconds, the CDE31 Series eliminates delays at the start of meetings, presentations, and scheduled signage. It ensures your content appears exactly when it???s needed??�ideal for corporate, retail, and education environments where every second counts. Future Ready, High-Performance Platform The CDE31 Series combines a powerful Quad-Core SoC with Android 14, 8GB RAM, and 32GB of storage to deliver smooth playback and responsive multitasking. Upgradable to Android 16, this robust platform ensures long-term compatibility, security, and performance, making it a future-ready display solution for evolving signage and collaboration needs. Flexible Orientation for Any Setup Supporting both landscape and portrait modes, this commercial-grade display adapts to a wide range of installation needs, from retail and digital menu boards to meeting room displays and campus communication. Native 4K Resolution for Uncompromised Detail The CDE31 Series delivers true native 4K resolution in both landscape and portrait modes, offering noticeably sharper and more detailed visuals than standard upscaled 4K. This ensures exceptional clarity and precise detail reproduction, making it ideal for text-heavy presentations and visually rich digital signage. Commercial-grade Digital Display Built for 24/7 operation, the CDE31 Series ensures uninterrupted communication across business-critical environments. It features 500 nits of brightness for clear, vibrant visuals, along with HDMI 2.1 input and 2.0 output for seamless screen duplication and tiling across up to 9 displays. Scheduled USB Media Playback The CDE31 Series supports USB playback for video, audio, and image files. Boot-on-Source functionality??�via USB Auto-Play or resume-last-source settings??�enables seamless, automated playback for digital signage without requiring a connected PC. Signal Failover for Continuous Playback When no signal is detected on the primary input, the CDE31 Series automatically switches to the next available source, ensuring uninterrupted content display. With configurable input priority, users can assign fallback sources such as alternate HDMI, USB-C, or a powered-on OPS to maintain uninterrupted content delivery in high-traffic environments like retail stores, transit hubs, and corporate lobbies where uptime is essential. Flexible Connectivity ??? One-Cable USB-C Connectivity The CDE31 Series features a USB-C port that supports audiovisual signal, fast data transfer, Ethernet, and 65W charging??�all through a single cable. Ideal for meeting rooms and shared workspaces, it allows users to plug in their laptop and instantly present, power up, and stay connected without extra adapters or clutter. Wireless Content Sharing The CDE31 Series offers wireless screen sharing through AirSync, allowing users to cast fro
Other features

Bundled softwareAirSync, Manager

Operational conditions

Operating relative humidity (H-H)20 - 80%
Operating temperature (T-T)0 - 40 ??C

Performance

PurposeCommercial
Operating hours (hours/days)24/7

Audio

Number of built-in speakers2
RMS rated power32 W
Built-in speaker(s)Yes

Power

Power consumption (typical)104.21 W
AC input voltage100 - 240 V
Energy efficiency class (SDR)F

Packaging content

Remote control includedYes
Cables includedAC, HDMI, RS-232
Batteries includedYes
Mounting kitYes

Packaging data

Package weight57 kg
Package depth225 mm
Package height1247 mm
Package width2110 mm

Logistics data

Pallet gross width2.14 m
Pallet gross length114 cm
Pallet gross height136.7 cm
Products per master (outer) case1 pc(s)
Harmonized System (HS) code8528521000

Ports & interfaces

Ethernet LANYes
USB connector typeUSB Type-A, USB Type-C
Ethernet LAN (RJ-45) ports2
DVI portNo
Digital audio optical out1
Wi-FiYes
PC Audio inYes
HDMI ports quantity4
Ethernet LAN data rates10,100,1000 Mbit/s
RS-232 interfaceYes
HDMI version2.0/2.1
DisplayPorts quantity0
PC Audio outYes
USB version2.0/3.2 Gen 1 (3.1 Gen 1)
DisplayPort version1.2
USB ports quantity3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
USB portYes
USB Type-C DisplayPort Alternate ModeYes
USB Power Delivery (USB PD)Yes
OPS module slotYes
HDMI input ports quantity3
HDMI output ports quantity1
USB Power Delivery up to65 W


Weight & dimensions

Weight42 kg
Display depth68 mm
Display height1101.7 mm
Display weight42 kg
Display width1930.8 mm

Computer system

Processor manufacturerARM
Operating system installedAndroid 14
Processor cores4
Built-in processorYes
Internal storage capacity32 GB
Processor architectureARM Cortex-A73
Internal memory8 GB

Design

Product colourBlack
Placement supportedIndoor
Panel mounting interface600 x 400 mm
Product designDigital signage flat panel
Bezel width (side)1.59 cm
Bezel width (top)1.59 cm
Bezel width (bottom)1.59 cm
Anti-glare screenYes
VESA mountingYes
Screen shapeFlat
OrientationHorizontal/Vertical

Display

Contrast ratio (typical)1200:1
Viewing angle, horizontal178??
Viewing angle, vertical178??
Display diagonal2.18 m (86")
Display brightness500 cd/m??
Response time8 ms
Display resolution3840 x 2160 pixels
TouchscreenNo
Contrast ratio (dynamic)5000:1
LED backlightYes
LED backlighting typeDirect-LED
Display technologyLCD
Native aspect ratio16:9
HD type4K Ultra HD
Panel life50000 h
Panel typeTFT
Active display area (W x H)1895.04 x 1065.96 mm
Surface hardness3H
Haze rate25%
Native refresh rate60 Hz
