Zebra Motorola Ls2208. Sensor Type: Laser Tilt Reading Angle:30 30?? Pitch Readi LS2208-SR20001R-UR

Motorola LS2208. Sensor type: Laser, Tilt reading angle: -30 - 30??, Pitch reading angle: -65 - 65??. Standard interfaces: USB. Product colour: White. Input voltage: 5 V, Power consumption: 130 mA. Weight: 146 g OUR BEST SELLING HANDHELD LASER SCANNER With over eight million sold, the LS2208 remains our best selling handheld laser scanner. The LS2208 has it all - enterprise class scanning in a very ergonomic and durable lightweight design that delivers all day comfort, an extra-long read range for easy scanning, plus support for everyday 1D bar codes, including high-density. With multiple interfaces, a universal cable and support for keyboards in 97 languages, the LS2208 delivers plug-and-play simplicity in virtually every corner of the world. The LS2208 - the well-proven scanner powering the checkout lines all around the world. Durable construction With its patented single board construction, patented frictionless liquid polymer scan element, scratch resistant tempered glass exit window and a stringent drop and tumble specification, the LS2208 delivers reliable all-day, every day operation. Capture high-density bar codes for greater application flexibility With just one scanner, you can capture the high density bar codes common on small items. Deploy in every corner of the world With support for 97 international keyboards, the LS2208 is ready for operation in your country, right out of the box. Class-leading working range Workers can capture everyday 13 mil UPC bar codes on items that are over 25 in./63.5 cm away, improving productivity and the customer checkout experience. Class-leading working range Workers can capture everyday 13 mil UPC bar codes on items that are over 25 in./63.5 cm away, improving productivity and the customer checkout experience. All day comfort your workers can count on The well-proven ergonomic and lightweight balanced design provides maximum comfort, even in the most scan intensive environments. The result? Reduced user fatigue and increased worker productivity. Flexible handheld or hands-free operation The optional IntellistandTM enables presentation scanning and allows workers to automatically switch between hands-free and handheld modes in the time it takes to drop the LS2208 into the stand. Multiple interfaces No matter what host you need to connect to today or tomorrow, the future proof LS2208 is ready. Truly plug-and-play The universal cable connects to any computing environment, practically eliminating setup and training time. Advanced Data Formatting (ADF) Format data properly before it is sent to your host computer, eliminating the costly modification of host software.
Interfaces/Ports

Host InterfaceUSB

Power Description

Input Voltage5 V DC

General Information

Product TypeBarcode Scanner Kit
Manufacturer Part NumberLS2208-SR20001R-UR
Manufacturer Website Addresshttp://www.zebra.com/gb/en
ManufacturerZebra Technologies Corporation
Product ModelLS2208
Product NameLS2208 Barcode Scanner Kit
Brand NameZebra

Technical Information

Barcode Symbology SupportedUPC/EAN
UPC/EAN Supplementals
UCC/EAN 128
Code 39
Code 39 Full ASCII
Code 39 TriOptic
Code 128
Code 128 Full ASCII
Codabar
Interleaved 2 of 5
Discrete 2 of 5
Code 93
MSI
Code 11
IATA
RSS Variants
Chinese 2 of 5

Connectivity TechnologyCable
Scanning Distance760 mm
Light SourceLaser
Drop SpecificationUnit functions normally after repeated 5 ft./1.5 m drops to concrete
Scan PatternBi-directional
Scan Rate100 scan/s
Image Sensor TypeLinear
Stand IncludedYes
Cable Type IncludedUSB
Scanning Capability1D
Reading Angle (Skew)60??
Reading Angle (Pitch)65??
Reading Angle (Roll)30??
Maximum Ambient Light86111 lux
Minimum Print Contrast20%
Minimum Element Resolution (Code 39)0.13 mm
Maximum Element Resolution (Code 39)1.02 mm


Physical Characteristics

Weight (Approximate)146 g
Form FactorHandheld
Height152.4 mm
Width63.5 mm
Depth84.8 mm
Product ColorWhite
Color FamilyWhite

Miscellaneous

Additional Information
Supported Interfaces:Serial
Keyboard Wedge
Wand Emulation
IBM 468X/469X
USB
Synapse

USB Cable separate

Application/UsageRetail
Education
Package ContentsSymbol LS2208 Handheld Barcode Scanner
USB Cable
Gooseneck Stand

CompatibilityIBM 468x/469x terminals.

Platform SupportedPC
Certifications & StandardsEnvironmental: RoHS 2002/95/EEC

Electrical Safety:UL1950
CSA C22.2 No. 950
EN60950/IEC950

EMI/RFI:FCC Part 15 Class B
ICES-003 Class B
European Union EMC Directive
Australian SMA
Taiwan EMC
Japan VCCI/MITI/Dentori

Laser Safety::CDRH Class II
IEC Class 2

Environmentally FriendlyYes
Ingress Protection (IP) RatingIP30
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
