Zyxel Xgs2220 Xgs2220-54Hp 50 Ports Manageable Layer 3 Switch Gigabit Ethernet 1 XGS2220-54-GB0101F

ZYXEL XGS2220 XGS2220-54HP 50 Ports Manageable Layer 3 Switch - Gigabit Ethernet, 10 Gigabit Ethernet - 100/1000Base-T, 10GBase-X, 10GBase-T - 3 Layer Supported - Modular - 754.11 W Power Consumption - 600 W PoE Budget - Optical Fiber, Twisted Pair - PoE Ports - Rack-mountable - Lifetime Limited Warranty The XGS2220 Series is a family of Layer 3 access Switch that consists of six models, including PoE, Non-PoE and fiber options. In addition to four 10G SFP+ uplink, all of them come with two additional 10G Multi-Gigabit (1G/2.5G/5G/10G) RJ-45 ports for more flexible connectivity. Non-PoE models XGS2220-30 and XGS2220-54 provide 24 or 48 Gigabit desktop ports for every day network access. PoE models XGS2220-30HP, XGS2220-54HP and XGS2220-54FP provide additional power over Ethernet capability and ready for WiFi 6/6E connectivity. The fiber option XGS2220-30F provides 24 SFP port, all serving the purpose to achieve business connectivity based on the flexibility of variety option of media interfaces and make itself an ideal choice for increasing business productivity. This Series is built with smart fan designed to automatically adjust speeds based on the device temperature, offering near silence while the Switch is in operation. Benefits | Sufficient and flexible 10G support - ideal for converged networking applications The XGS2220 provides up to six high performance 10 Gigabit connectivity including two 10G Multi-Gigabit ports and four SFP+ ports for Layer 3 access network. These 10G uplinks offer the flexibility to connect to servers, network storages, or other high-speed network devices with either 10G copper or fiber connection. In addition, the SFP+ ports can be used to connect to aggregation switches for backbone services or resiliency. This series switch has a full Layer 2 feature set that can shape the traffic for diverse VoIP, video conference, IPTV and networked AV deployments. Advanced traffic control features such as L2 multicast, IGMP snooping, Multicast VLAN Registration (MVR) provide hotels, businesses and educational institutions greater agility and more effective traffic management for the converged applications of today. Dedicated networked AV mode The standard switch interface includes an abundance of generic networking features to address a wide variety of applications, making it a challenge for traditional AV system integrators to setup an IP-based network that needs to run Audio and Video services. The tailor-made networked AV mode begins with an intuitive wizard that prompts for high-level requirement for network infrastructure, followed up with AI-intelligent to apply all the necessary details to setup a professional AVoIP system. With the intuitive graphical status overview of the key AV network elements such as IGMP and IP information, accompanied with condensed function menu helps you manage and monitor the system with ease.
Management & Protocols

ManageableYes

Reliability

MTBF214388 Hour

I/O Expansions

Expansion Slot TypeSFP+
Number of SFP+ Slots4
Total Number of Expansion Slots4.0

Miscellaneous

Application/UsageBranch Office
Business
Network
Package Contents48-port GbE L3 Access PoE+ Switch with 6 10G Uplink (600 W)
Power Cord
Rack Mounting Kit


Physical Characteristics

Weight (Approximate)5 kg
Form FactorRack-mountable
Height44 mm
Width441 mm
Depth330 mm

Network & Communication

Layer Supported3
Networking StandardsIEEE 802.1p
IEEE 802.1s
IEEE 802.1w
IEEE 802.1x
IEEE 802.3ab
IEEE 802.3ae
IEEE 802.3af
IEEE 802.3an
IEEE 802.3at
IEEE 802.3az
IEEE 802.3bt
IEEE 802.3x
IEEE 802.3z
IEEE 802.1Q
IEEE 802.11ac
IEEE 802.11ax
IEEE 802.1ab
IEEE 802.1ad
IEEE 802.1D


Media & Performance

Network Technology100/1000Base-T GBase-T GBase-X
Ethernet Technology10 Gigabit Ethernet
Gigabit Ethernet
Media Type SupportedTwisted Pair
Optical Fiber

General Information

Product TypeLayer 3 Switch
Manufacturer Part NumberXGS222054GB0101F
Manufacturer Website Addresshttp://www.zyxel.co.uk
ManufacturerZYXEL Communications Corp.
Product ModelXGS2220-54HP
Product Name48-port GbE L3 Access PoE+ Switch with 6 10G Uplink (600 W)
Product SeriesXGS2220
Brand NameZYXEL

Interfaces/Ports

Network (RJ-45)Yes
ModularYes
Uplink PortYes
Total Number of Network Ports50
Port/Expansion Slot Details40 x Gigabit Ethernet PoE+
8 x Gigabit Ethernet PoE++
4 x 10 Gigabit Ethernet Expansion Slot
2 x 10 Gigabit Ethernet PoE++

Power Description

Input Voltage230 V AC 0 V AC
Power SourcePower Supply
Frequency50 Hz
60 Hz
Power Consumption754.11 W
PoE (RJ-45) PortYes
PoE Budget600 W
