ACTi E14 E14. 10M Cube WDR E14

- 10 Megapixel with 4K/1080p
- Fixed Lens with f3.6mm / F1.8
- Basic WDR (70 dB)
- 30 fps at 1920 x 1080
- Wide Angle

Audio



Audio formats supported



PCM


Audio system



1-way


Built-in microphone



Yes


Sample rate



8 kHz


Camera



Camera shutter speed



1/5 - 1/10000 Second


Camera shutter type



Electronic


Minimum illumination



0.1 lx


White balance



Auto, Manual


Design



Form factor



Cube


Mounting type



Ceiling/wall


Product colour



Black, White


Image sensor



Optical sensor size



1/3.2 "


Sensor type



CMOS


Network



Cabling technology



10/100Base-T(X)


Ethernet LAN



Yes


Supported network protocols



TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP, UPnP, SNMP, Bonjour


Wi-Fi



No


Operational conditions



Operating relative humidity (H-H)



10 - 85 %


Operating temperature (T-T)



-10 - 45 °C


Storage relative humidity (H-H)



10 - 85 %


Storage temperature (T-T)



-10 - 45 °C


Package dimensions



Depth (package,cm)



9.1 cm


Gross Weight (Package, kg)



1 kg


Height (package,cm)



20 cm


Width (package,cm)



13.8 cm


Packaging content



Manual



Yes


Performance



Connectivity technology



Wired


Day/night mode



Yes


Placement supported



Indoor


Type



IP security camera


Wide Dynamic Range (WDR)



Yes


Ports & interfaces



Ethernet LAN (RJ-45) ports



1


Headphone outputs



1


Interface



RJ-45


Power



Power consumption (typical)



3.84 Watt


Power over Ethernet (PoE)



Yes


Power source type



PoE


Product dimensions



Net Weight (Product, kg)



0.38 kg


Product Depth



4.5 cm


Product Height



9.6 cm


Product Width



9.6 cm


Security



HTTPS encryption



Yes


IP address filtering



Yes


Password protection type



User


Security algorithms



802.1x RADIUS


Video motion detection



Yes


Storage



Built-in HDD



No


Card reader integrated



Yes


Compatible memory cards



MicroSD (TransFlash), MicroSDHC, MicroSDXC


Vendor information



Brand Name


ACTi


Warranty



3 Year(s)


Video



Frame rate



30 fps


Maximum resolution



3648 x 2736 Pixels


Supported graphics resolutions



320 x 240, 2592 x 1944, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA), 640 x 480 (VGA), 800 x 600 (SVGA)


Supported video modes



1080p, 720p


Total megapixels



10 MP


Video formats supported



H.264, M-JPEG
