Apc Rack Pdu 2G Metered By Outlet With Switching Zerou 20A/208V 16A/230V 21 C13 AP8659

APC Rack PDU 2G, Metered by Outlet with Switching, ZeroU, 20A/208V, 16A/230V, (21) C13 & (3) C19. PDU types: Metered, Metered-by-outlet, Switched, Rack capacity: 0U, Mounting: Vertical. AC outlets quantity: 24 AC outlet(s), AC outlet types: C13 coupler, C19 coupler. Monitoring: Current, Power, Voltage, Outlet control: Lock-out, Recycle, Turn off, Turn on. Nominal input voltage: 200-230 V, Maximum current: 16 A, AC input frequency: 50 - 60 Hz. Compliance certificates: RoHS, Certification: EN 5502 APC Metered by Outlet with Switching Rack Power Distribution Units (PDUs) enable advanced, user-customizable power control and individual outlet power metering Remote outlet level controls allow power on/off functionality for power recycling to reboot locked-up equipment and to avoid unauthorized use of individual outlets Power sequencing delays allow users to define the order in which to power up or down attached equipment Avoid circuit overload during power recovery and extend uptime of critical equipment by prioritizing the load shedding Current metering provides real-time remote monitoring of connected loads Switched Rack PDUs include real power monitoring, a temperature/humidity sensor port, and locking IEC receptacles User-defined alarms warn of potential circuit overloads before critical IT failures occur Users can access, configure, and control Switched rack PDUs through secure Web, SNMP, or Telnet Interfaces and is complimented by APC Centralized Management platforms using InfraStruxure Central, Capacity Manager and Change Manager
Management

Management
Protocols:SNMP
Telnet


Technical Information

Plug/Connector TypeIEC 60320 C20
PDU TypeMetered-by-Outlet

Power Description

Input Voltage208 V
230 V 0 V
Output Voltage208 V AC
230 V AC 0 V AC 0 V AC

Physical Characteristics

Weight (Approximate)6.09 kg
Form FactorTower
Mount TypeRack-mountable
Rack Height0U
PlacementSide
Height1829 mm
Width56 mm
Depth51 mm
Mounting OrientationVertical
Mounting PreferenceNo Preference


General Information

Product TypePDU
Manufacturer Part NumberAP8659
schneider-electric
ManufacturerSchneider Electric SA
Product NameMetered-by-Outlet Rack PDU
Product LineNetShelter
Product SeriesSwitched Metered
Brand NameAPC by Schneider Electric

Miscellaneous

Mercury FreeYes
For Country/RegionUnited States
Product Take Back ProgramNo
RoHS Exemption Information download.schneider-electric/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=AP8659_ROHS_DECLARATION&p_FileName=AP8659KIT_ROHS_DECLARATION_US.pdf
REACH Declaration URL checkaproduct.se/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=323194454&lang=en-us
EU RoHS Declaration URL checkaproduct.se/DistantRequestDispatcher.aspx?action=export&pid=323194454&lang=en-us
Environmental Profile Availability download.schneider-electric/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1612033EN
End of Life Manual Availability download.schneider-electric/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1612033_EN
REACH free of SVHCYes
Lead FreeYes
WEEE StatementThe product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
