Apc Smart-Ups SMT1500RMI1U 4X C13 Usb Rackmount 1U 1500Va. Ups Topology: Line-In SMT1500RMI1U

APC Smart-UPS SMT1500RMI1U - 4x C13, USB, Rackmount 1U, 1500VA. UPS topology: Line-Interactive, Output power capacity: 1.5 kVA, Output power: 1000 W. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 4 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 293 VAh, Typical backup time at full load: 4.8 min. Form factor: Rackmount, Product colour: Black, Rack capacity: 1U. Compliance certificates: RoHS, Certification: CE, EAC, EN/IEC 62040-1, EN/IEC Always stay online and prevent data loss As soon as the power fails, an APC Smart-UPS immediately supplies emergency power to all connected equipment. Because an APC UPS does this automatically, you prevent unwanted failure of, for example, a PC, server or switch. With the included Powershute software, you can even have critical IT hardware shut down automatically and in a controlled manner. This prevents data loss, downtime and physical damage to hardware. Safety In addition, a Smart-UPS protects connected devices against peak voltage caused by lightning, among other things. This APC emergency power supply is ideally suited for (small) business use. Network Management Card If you connect the UPS directly to your network via the optional APC Network Management Card (AP9640/AP9641), it can be easily managed remotely via SNMP or our remote management software Ecostruxure IT Expert (SFTWES1-DIGI). You can also automatically send a shutdown signal via the network to multiple physical and/or virtual servers. By means of the APC PowerChute Network Shutdown Software belonging to the network card, it is even possible to differentiate the shutdown moment and the order in which this happens. Extend the lifespan The internal battery cartridge (APCRBC88) can be replaced easily, safely and independently by the user. This without having to switch off the APC SMT1500RMI1U or connected equipment. This way you can easily and cheaply extend the lifespan of the APC Smart-UPS and your equipment always remains online. Warranty extension The factory warranty of the SMT1500RMI1U is 3 years, with the exception of the battery cartridge, which has a factory warranty of 2 years. Both are extended by 3 years to 6 and 5 years respectively with the APC service pack (WBEXTWAR3YR-SP-03). Ease of use By means of physical buttons and an LCD screen, it is possible to set and read out the basic functionalities. Thanks to the included 4-post rail kit, you can easily mount the UPS in a rack. Service and support by people who know your APC UPS best. How do you maximize UPS performance and fix OpEx costs? Choose Schneider Electric's 5-year EcoCare Service* (ECO1PH5YFW03):- 24/7 remote monitoring by SE's Connected Services Hub - On-site repair service (incl. replacement UPS/parts/battery and labor). - 5-year warranty - Technical support from our experts, on-site and remote - Maintenance recommendations & insights *network card required (ap9640/ap9641) This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. The 1500VA line interactive 1U rackmount UPS provides pure sine wave power to support critical electronics during power disruptions. It comes with IEC 320 C14 input, 4x IEC 320 C13 outlets, and 2x IEC jumper cables. It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. It provides surge protection against lightning strikes, power sags, brownouts and surges. The SMT UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. It is compatible with a dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications.
Management

AlarmOn Battery
Configurable Delay
Low Battery

Interfaces/Ports

USBYes
Network (RJ-45)Optional
Serial PortYes
Total Number of Expansion Slots1

Battery Information

Battery ChemistryLead Acid
Hot SwappableYes
Backup/Run Time (Half Load)17 Minute
Backup/Run Time (Full Load)5 Minute
Battery CharacteristicsSpill-proof, Maintenance-free
Typical Battery Recharge Time4 Hour

Power Description

Input Voltage230 V
Output Voltage230 V AC
Input Current12 A
Surge Energy Rating540 J
Waveform TypeSine Wave
Load Capacity (VA)1.50 kVA
Load Capacity (Watt)1 kW

Miscellaneous

Package ContentsSmart-UPS 1500VA LCD RM 1U 230V
CD with Software
Documentation CD
Installation Guide
Rack Mounting Support Rails
Smart UPS Signaling RS-232 Cable
USB Cable
Warranty Card

Certifications & StandardsUL 1449
Environmentally FriendlyYes
Mercury FreeYes
For Country/RegionUnited States
Optimized Energy EfficiencyYes
Product Take Back ProgramYes
REACH free of SVHCNo
WEEE StatementThe product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Environmental ComplianceRegistration, Evaluation, Authorization and Restriction of Chemicals (REACH)
Restriction of Hazardous Substances (RoHS)


Technical Information

Protection TypeSurge
Spike
Lightning
Plug/Connector TypeIEC 60320 C14
Cord Length2.44 m
Receptacle TypeIEC 60320 C13
Receptacle Detail4 x IEC 320-C13
2 x IEC Jumper

General Information

Product TypeLine-interactive UPS
Manufacturer Part NumberSMT1500RMI1U
schneider-electric
Packaged Quantity1 Each
ManufacturerSchneider Electric SA
Product NameSmart-UPS 1500VA LCD RM 1U 230V
Product LineSmart-UPS
Product SeriesSMT
Brand NameAPC by Schneider Electric

Physical Characteristics

Weight (Approximate)24.09 kg
Form FactorRack-mountable
Rack Height1U
Height44 mm
Width432 mm
Depth665 mm
Product ColorBlack
Color FamilyBlack
Mounting LocationFront
Mounting PreferenceLower
