Axis 02375-001 M3088-V 02375-001

M3088-V is an ultra-compact, indoor fixed mini dome with Deep Learning Processing Unit (DLPU). Dust - and IK08 vandal-resistant casing, fixed lens, horizontal/vertical field of view 109�/56�. D/N functionality with automatically removable IR-cut filter. Multiple, individually configurable H.264, H.265 and Motion JPEG streams; max 8MP at 15 fps with WDR. Zipstream for reduced bandwidth and storage. MicroSD memory card slot for local storage. Audio and I/O with optional accessories. Object Analytics, video motion detection and active tampering alarm. Edge Vault for increased cybersecurity. Powered by IEEE 802.3af/802.3at Type 1 Class 2

Audio



Audio system



2-way


Camera



Angle of rotation



175 �


Camera shutter speed



1/71500 - 1/5 Second


Lens viewing angle, horizontal



109 �


Lens viewing angle, vertical



56 �


Minimum illumination



0.25 lx


Pan range



0 - 175 �


Tilt angle range



0 - 80 �


Design



Form factor



Dome


Housing material



Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC)


IK code



IK08


International Protection (IP) code



IP42


Mounting type



Ceiling/wall


Product colour



White


Protection features



Dust resistant, Impact resistant, Water resistant


Image sensor



Number of sensors



1


Optical sensor size



1/2.8 "


Progressive scan



Yes


Sensor type



CMOS


Lens system



Focal length range



2.9 mm


Network



Bluetooth



No


Ethernet LAN



Yes


Networking standards



IEEE 802.1x, IEEE 802.3af, IEEE 802.3at


Number of users



1 user(s)


Quality of Service (QoS) support



Yes


Wi-Fi



No


Night vision



Night vision



Yes


Operational conditions



Operating relative humidity (H-H)



10 - 85 %


Operating temperature (T-T)



0 - 40 �C


Storage relative humidity (H-H)



5 - 95 %


Storage temperature (T-T)



-40 - 65 �C


Package dimensions



Depth (package,cm)



11 cm


Gross Weight (Package, kg)



0.28 kg


Height (package,cm)



9 cm


Width (package,cm)



12 cm


Packaging content



Manual



Yes


Number of cameras



1


Performance



Alarm input/output



Yes


Connectivity technology



Wired


Day/night mode



Yes


Infrared (IR) cut-off filter



Yes


Languages support



Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Korean, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese


Number of languages



18


Placement supported



Indoor


PTZ control



Yes


PTZ modes



Digital PTZ


Type



IP security camera


Wide Dynamic Range (WDR)



Yes


Ports & interfaces



Ethernet LAN (RJ-45) ports



1


Power



Power consumption (max)



4.2 Watt


Power consumption (typical)



3.6 Watt


Power source type



PoE


Product dimensions



Net Weight (Product, kg)



0.28 kg


Product Depth



11 cm


Product Height



9 cm


Product Width



12 cm


Security



Digest authentication



Yes


HTTPS encryption



Yes


IP address filtering



Yes


Network access storage (NAS)



Yes


Password protection



Yes


Pixel counter



Yes


Video motion detection



Yes


Storage



Built-in HDD



No


Card reader integrated



Yes


Compatible memory cards



MicroSD (TransFlash), MicroSDHC, MicroSDXC


Flash memory



512 MB


Internal memory



2048 MB


Technical details



Doesn't contain



BFR, PVC


Warranty period



5 year(s)


Vendor information



Brand Name


Axis


Video



Frame rate



15 fps


Image quality adjustment



Brightness, Contrast, Sharpness


Maximum resolution



3840 x 2160 Pixels


Privacy masking



Yes


Total megapixels



8 MP


Video compression formats



H.264, H.265, M-JPEG, MPEG4


Weight & dimensions



Diameter



10.1 cm
