Cisco MR18-HW-RFB Meraki MR18 Cloud-Managed 2x2 MR18-HW-RFB

Dual-band cloud-managed wireless LAN
The Cisco Meraki MR18 is an industry-first three-radio, cloud managed 2x2 MIMO 802.11n access point designed for deployments in offices, schools, hospitals, hotels, and large retail stores. The MR18 features dual-concurrent, dual-band operation and advanced 802.11n technologies such as MIMO and beam forming, delivering the high throughput and reliable coverage required by demanding business applications like voice and video. Not only does the MR18 provide speeds of up to 600 Mbps with two concurrent 2x2:2 MIMO radios, but also delivers unprecedented security and spectrum visibility via a third radio dedicated to 24x7 WIDS/WIPS and advanced RF analytics.

MR18 and Meraki Cloud Management: A Powerful Combo
The MR18 is managed via the Meraki cloud, with an intuitive browserbased interface that lets you get up and running quickly without training or certifications. Since the MR18 is self-configuring and managed over the web, it can even be deployed at a remote location without on-site IT staff.

The MR18 is monitored 24x7 via the cloud, which delivers real-time alerts if your network encounters problems. Remote diagnostics tools enable real-time troubleshooting over the web, meaning multi-site, distributed networks can be managed remotely.

The MR18�s firmware is always kept up to date from the cloud. New features, bug fixes, and enhancements are delivered seamlessly over the web, meaning no manual software updates to download or missing security patches to worry about.

Dual enterprise class 802.11n radios, up to 600 Mbps
The MR18 features two powerful radios and advanced RF design for enhanced receive sensitivity. Combined with 802.11n technologies including 2x2 MIMO and transmit beamforming, the MR18 delivers data rates of up to 600 Mbps and enhanced coverage, meaning fewer access points are required for a given deployment. In addition, the MR18 uses band steering to automatically serve 5 GHz-capable clients with the 5 GHz radio, maximizing capacity in the 2.4 GHz range for older 802.11b/g and 2.4 GHz-only clients.

Dedicated third radio delivers 24x7 wireless security and RF analytics*
The MR18�s dedicated dual-band third radio scans the environment continuously, characterizing RF interference and containing wireless threats like rogue access points. No more need to choose between wireless security, advanced RF analysis, and serving client data: a dedicated third radio means that all three occur in real-time, without any impact to client traffic or AP throughput.

Application-aware traffic shaping
The MR18 includes an integrated layer 7 packet inspection, classification, and control engine, enabling QoS policies based on traffic type. Integrated support for Wireless Multi Media (WMM) and 802.1p DSCP tagging. Prioritize your mission critical applications, while setting limits on recreational traffic, e.g., peer-to-peer and video streaming.

Automatic RF optimization with spectrum analysis
The MR18�s sophisticated, automated RF optimization means that there is no need for the dedicated hardware and RF expertise typically required to tune a wireless network. An integrated spectrum analyzer monitors the airspace for neighboring WiFi devices as well as non-802.11 interference � microwave ovens, Bluetooth headsets, etc. The Meraki cloud then automatically optimizes the MR18�s channel selection, transmit power, and client connection settings, providing optimal performance even under challenging RF conditions.

Integrated enterprise security and guest access
The MR18 features integrated, easy-to-use security technologies to provide secure connectivity for employees and guests alike. Advanced security features such as AES hardware-based encryption and WPA2-Enterprise authentication with 802.1X and Active Directory integration provide wire-like security while still being easy to configure. One-click guest isolation provides secure, Internet-only access for visitors. The integrated policy firewall (Identity Policy Manager) enables granular group or device-based access control. Meraki Teleworker VPN makes it easy to extend the corporate LAN to remote sites, without requiring clients and devices to have client VPN software. PCI compliance reports check network settings against PCI requirements to simplify secure retail deployments.

Secure wireless environments 24x7 using Air Marshal
There�s no need to choose between a wireless intrusion prevention system (WIPS) and serving client data: thanks to the dedicated third radio, Air Marshal, a highly optimized built-in WIPS, scans continuously for threats and remediates them as commanded, all without disrupting client service. Alarms and auto-containment of malicious and rogue APs are configured via flexible remediation policies, ensuring optimal security and performance in even the most challenging wireless environments.

High performance mesh
The MR18�s advanced mesh technologies like multi-channel routing protocols and multiple gateway support enable scalable, high throughput coverage of hard-to-wire areas with zero configuration. Mesh also improves network reliability � in the event of a switch or cable failure, the MR18 will automatically revert to mesh mode, providing continued gateway connectivity to clients.

Self-configuring, self-optimizing, self-healing
When plugged in, the MR18 automatically connects to the Meraki cloud, downloads its configuration, and joins the appropriate network. It self optimizes, determining the ideal channel, transmit power, and client connection parameters. It also self heals, responding automatically to switch failures and other errors.

Low profile, environmentally friendly design
Despite its incredible power and feature set, the MR18 is the lowest profile 802.11n access point available � at just one inch thick, it blends seamlessly into any environment. In addition to looking great, the MR18 is earth friendly: we�ve eliminated excess packaging and documentation, and 90% of the access point materials are recyclable. A maximum power draw of only 9.8 watts and a cloud-managed architecture mean that pollution, material utilization and electricity bills are minimized.

* Maximum hardware capability shown above. Transmit power is configurable in increments of 1 dB and is automatically limited to comply with local regulatory settings.

Antenna



Antenna features



Integrated antenna


Antenna gain level (max)



5 dBi


Antenna type



Omni-directional


Design



Cable lock slot



Yes


Certification



Anatel (Brazil), FCC (US), IC (Canada), CE (Europe), C-Tick (Australia/New Zealand), RoHS, UL2043


Internal



No


LED indicators



LAN, Power, Status


Placement



Ceiling, Table, Wall


Product colour



White


Features



2.4 GHz



Yes


5 GHz



Yes


Automatic channel selection



Yes


Channel bandwidth



40 MHz


Channels quantity



2 channels


Ethernet LAN data rates



100, 1000


Maximum data transfer rate



600 Mbit/s


Networking standards



IEEE 802.11a, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.1p, IEEE 802.3af


Quality of Service (QoS) support



Yes


Transmitting power



24 dBmW


Virtual LAN features



Tagged VLAN


VLAN support



Yes


Wi-Fi Multimedia (WMM)/(WME)



Yes


Management features



Firmware upgradeable



Yes


Web-based management



Yes


Operational conditions



Operating relative humidity (H-H)



5 - 95 %


Operating temperature (T-T)



0 - 40 �C


Package dimensions



Gross Weight (Package, kg)



1 kg


Packaging content



AC adapter included



Yes


Mounting kit



Yes


Ports & interfaces



DC-in jack



Yes


Ethernet LAN (RJ-45) ports



1


WAN connection



Ethernet (RJ-45)


Power



AC input voltage



24 - 57 V


Power consumption (typical)



9.8 Watt


Power over Ethernet (PoE)



Yes


Product dimensions



Net Weight (Product, kg)



1 kg


Product Depth



14.6 cm


Product Height



3 cm


Product Width



18.6 cm


Security



Security algorithms



AES, IPSEC, TKIP, WEP, WPA, WPA2, WPA2-PSK


VPN support



IPsec


Vendor information



Brand Name


Cisco


Warranty



1 Month(s)
