Cisco SB SG500X-48-K9-G5-RFB 48p GB + 4p 10GB Stackable SG500X-48-K9-G5-RFB

The Cisco SG500X-48 is a 48-port stackable managed Gigabit Ethernet switch, with 4 Enhanced Small Form-Factor Pluggable (SFP+) slots and optional 10 Gigabit Ethernet connectivity, that provides a solid foundation for your current business applications, as well as those you are planning for the future. It offers true stacking, advanced security, quality of service, energy-saving technology (EEE), IPv6, and network features that deliver the reliability and performance needed by demanding environments. The switch is easy to configure and manage with a choice of management tools and is offered with a limited lifetime warranty, including next-business-day advance replacement and one year of technical support. The Cisco SG500X-48 provides the ideal technology foundation at a price you can afford, and in a solution designed to grow with your business.

- Layer 3 - Managed
- 48 x 10/100/1000 + 4 x 10 Gigabit SFP+ ports
- Rack-mountable
- Stackable

Data transmission



Jumbo frames



9216


Jumbo frames support



Yes


MAC address table



16000 entries


Maximum data transfer rate



10 Gbit/s


Number of IP interfaces



256


Number of queues



8


Number of static routes



2048


Packet buffer memory



24 MB


Switching capacity



176 Gbit/s


Throughput



130.95 Mpps


Design



Certification



UL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A


LED indicators



Link, PoE


Number of fans



2 fan(s)


Product colour



Black


Reset button



Yes


Stackable



Yes


Management features



ARP inspection



Yes


MIB support



Y


Quality of Service (QoS) support



Yes


Switch layer



L2/L3


Switch type



Managed


Web-based management



Yes


Multicast features



Multicast support



Yes


Network



10G support



Yes


Broadcast storm control



Yes


Copper ethernet cabling technology



1000BASE-T, 100BASE-TX, 10BASE-T


Ethernet LAN data rates



10, 100, 1000


Flow control support



Yes


Head-of-line (HOL) blocking



Yes


Link aggregation



Yes


Networking standards



IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z


Number of VLANs



4096


Port mirroring



Yes


Rate limiting



Yes


Spanning tree protocol



Yes


Virtual LAN features



Private VLAN, Tagged VLAN


VLAN support



Yes


Operational conditions



Heat dissipation



189.5 BTU/h


Operating relative humidity (H-H)



10 - 90 %


Operating temperature (T-T)



32 - 104 �F


Operating temperature (T-T)



0 - 40 �C


Storage relative humidity (H-H)



10 - 90 %


Storage temperature (T-T)



-20 - 70 �C


Other features



Ethernet interface type



Gigabit Ethernet


Ethernet LAN



Yes


Package dimensions



Gross Weight (Package, kg)



4.1 kg


Packaging data



Cables included



AC, Serial


Mounting brackets included



Yes


Quick start guide



Yes


Resource CD



Yes


Performance



Built-in processor



Yes


Compatible operating systems



Windows, Linux, Mac OS X


Firmware upgradeable



Yes


Flash memory



32 MB


Internal memory



256 MB


Mean time between failures (MTBF)



166796.4 Hour


Minimum system requirements



Mozilla Firefox 3.6+ IE 7+


Noise level



41.1 dB


Processor frequency



800 MHz


Ports & interfaces



Basic switching RJ-45 Ethernet ports quantity



48


Basic switching RJ-45 Ethernet ports type



Gigabit Ethernet (10/100/1000)


Combo SFP ports quantity



2


SFP+ module slots quantity



2


Power



AC input frequency



47/63 Hz


AC input voltage



100 - 240 V


Power consumption (typical)



60.3 Watt


Power supply included



Yes


Power over Ethernet (PoE)



Power over Ethernet (PoE)



No


Product dimensions



Net Weight (Product, kg)



4.01 kg


Product Depth



25.7 cm


Product Height



4.4 cm


Product Width



44 cm


Protocols



Management protocols



SNMP v1/v2c/v3, MIB, HTTP/HTTPS, RMON, IPv4, IPv6


Supported network protocols



IPv6


Security



Access Control List (ACL)



Yes


BPDU filtering/protection



Yes


DHCP features



DHCP server, DHCP client


IGMP snooping



Yes


Loop protection



Yes


Security algorithms



802.1x RADIUS, SSH, SSL/TLS


SSH/SSL support



Yes


Vendor information



Brand Name


Cisco SB


Homepage



http://www.cisco.com


Warranty



1 Year(s)
