Datalogic Magellan 900I. Type: Fixed Bar Code Reader Scanner Type: 1D/2D Sensor MG0901-10000-0200

Datalogic Magellan 900i. Type: Fixed bar code reader, Scanner type: 1D/2D, Sensor type: LED. Connectivity technology: Wired, Standard interfaces: USB, Cable length: 2 m. Product colour: Black, International Protection (IP) code: IP52, Protection features: Drop resistant. Power source type: USB, Input voltage: 5 V, Power consumption: 300 mA. Weight: 345 g, Width: 76 mm, Depth: 78 mm HIGH PERFORMANCE SCANNING FOR YOUR BUSINESS The Magellan 900i omnidirectional presentation scanner is a versatile addition to any point-of-sale or service counter. With Datalogic's latest digital imaging technology, it seamlessly decodes both 1D and 2D barcodes on everything from printed product labels to mobile coupons, loyalty cards, tickets and boarding passes. Equally at home in sweep or presentation scanning applications, the Magellan 900i makes it easy to read any bar code in any situation. A WIDE VARIETY OF USES The simple, clean aesthetic of the Magellan 900i makes it blend into any store format and with any point-of-sale system. It is equally at home in a pharmacy, convenience store, movie theater or a boutique. The compact footprint maximizes stability and space efficiency. The intelligent host cable routing common to all Magellan scanners ensures that the 900i is both comfortable in the hand and can back right up to a wall or display for maximum space efficiency. The optional kiosk/OEM mount makes for a seamless integration into a small point-of-sale, access control kiosk, or customer ordering station. ENTERPRISE FEATURES Remote Management is supported for OPOS, JavaPOS, Toshiba Remote Management with IBM Systems Director and Wavelink Avalanche. Additional capabilities are available with the Value Added features included in every Magellan scanner.
Interfaces/Ports

Host InterfaceSerial
USB

Technical Information

Barcode Symbology Supported
1D:Auto discriminates all standard 1D codes including GS1 DataBar linear codes.

2D:Aztec Code
Data Matrix
MaxiCode
QR Code

Postal Codes:Australian Post
British Post
Canadian Post
China Post; IMB
Japanese Post
KIX Post
Planet Code
Portuguese Post
Postnet;
Royal Mail Code (RM4SCC)
Swedish Post

Stacked Codes:GS1 DataBar Composites
GS1 DataBar Composites
GS1 DataBar Expanded Stacked
GS1 DataBar Stacked
GS1 DataBar Stacked Omnidirectional
Micro PDF417
PDF417

Connectivity TechnologyCable
FeaturesCheckpoint EAS
Ergonomic Design
Notification LED
Beep
Scanning Distance279.40 mm
Light SourceLED
Image FormatsJPEG
BMP
Drop SpecificationWithstands repeated drops from 1.2 m / 4.0 ft onto a concrete surface

Scan PatternArea
Omni-directional
Image Sensor TypeImager
Illumination TypeLED
Stand IncludedYes
Cable Type IncludedUSB
Scanning Capability1D
2D
Reading Angle (Skew)70??
Reading Angle (Pitch)70??
Reading Angle (Roll)360??
Maximum Ambient Light86100 lux
Minimum Print Contrast25%
Minimum Element Resolution (DataMatrix)0.25 mm
Maximum Element Resolution (DataMatrix)0.38 mm
Air Electrostatic Discharge (+/-)25kV
Image Sensor Resolution1280 x 800


Physical Characteristics

DurabilityDust Resistant
Water Resistant
Form FactorDesktop
Product ColorBlack
Color FamilyBlack

Miscellaneous

Application/UsageRetail
Pharmacy
Laboratory
Healthcare
Commercial Service
Convenience Store
Ingress Protection (IP) RatingIP52

General Information

Product TypeBarcode Scanner Kit
Manufacturer Part NumberMG0901-10000-0200
datalogic
ManufacturerDatalogic S.p.A
Product Model900i
Product NameMAGELLAN 900i Barcode Scanner Kit
Product LineMagellan
Brand NameDatalogic
