Datalogic Skorpio X4 X40 Handheld Terminal 2D 1D Led Light Source Imager 10 M Qu 946400005

Datalogic Skorpio X4 X40 Handheld Terminal - 2D, 1D - LED Light Source - Imager - 10 m - Qualcomm - QCM4490 - 10.2 cm (4") - LED - WVGA - 480 x 800 - Touchscreen - 6 GB RAM / 128 GB Flash - Bluetooth - Wireless LAN IEEE 802.11 a/b/g/n/ac/ax/d/h/i/r/k/v/w/mc (Wi-Fi 6) - Rear Camera - 48 Keys - Numeric Keyboard - Android 15 Upgradable to Android 19 - Gun - Battery Included - IP65, IP67 Choose Excellence. Built for Agility | ALL-DAY COMFORT, DESIGNED FOR REAL WORK Built for high-intensity retail, light warehousing and manufacturing, the Skorpio X40/X45's compact, well-balanced design sits naturally in the hand - reducing strain and fatigue across long shifts so operators stay productive from receiving to shipping. VERSATILE DATA ENTRY AND FIELD ADAPTABILITY Three keyboard layout options with large, well-spaced keys deliver confident, accurate input in any application - even with gloves on. The field-detachable handle lets operators switch instantly between handheld and pistol grip, adapting to the task without slowing down. NEVER MISS A SCAN WITH GREEN SPOT Know instantly when a scan is good. Datalogic's patented Green Spot technology projects a visible confirmation directly onto the label, keeping eyes on the work and doubt out of the picture. Paired with high-performance 2D imagers for fast, accurate reading of 1D and 2D barcodes in any condition, the Skorpio X40/X45 keeps operations moving without missing a beat. CONNECTED ACROSS YOUR ENTIRE OPERATION Stay connected across your entire operation - indoors or out. Fast data sync, seamless roaming and the power to run modern enterprise apps without slowing down. Powered by Qualcomm- 4490 with 5G and Wi-Fi 6E, and built for Android™ enterprise with the long device lifecycle your fleet depends on. ZERO DOWNTIME. ZERO COMPROMISE The Skorpio X40/X45 supports both contact and wireless charging - with wireless eliminating the contact wear, debris build-up and maintenance of traditional pin charging. Full backward compatibility with Skorpio X5 docks and accessories means upgrading your devices doesn't mean replacing your infrastructure.
Power Description

Power SourceBattery

Camera

Rear CameraYes
Rear Camera Resolution13 Megapixel

Interfaces/Ports

USBYes
USB Type-CYes

Keyboard/Keypad

Number of Keys48
Keyboard TypeNumeric

Physical Characteristics

Form FactorGun
Weight (With Battery)575 g

Software

Operating SystemAndroid 15
Upgradable Operating SystemAndroid 19

Touchscreen Information

TouchscreenYes
Multi-touch ScreenYes
Number of Simultaneous Touchpoints5

Display & Graphics

Screen Resolution480 x 800
Screen Size10.2 cm (4")
Screen ModeWVGA
Display Screen TypeLED

Technical Information

Brightness450 cd/m-
Connectivity TechnologyWired/Wireless
FeaturesVibration Alert
Oil Resistant
Push-to-talk
Tumble Proof
Lightweight
Green Spot Technology
Gorilla Glass
Fingerprint Resistant
Fast Charging
Drop Resistant
Drop Proof
Chemical Resistant
Sensor TypeGyroscope
Proximity
Magnetometer
eCompass
Accelerometer
Ambient Lighting
Scanning Distance10 m
Light SourceLED
Scanner RangeLong Range
Drop SpecificationMultiple 2.4m/8ft drops to concrete at ambient temperature per MIL STD 810H;
Multiple 1.8m/6ft drops to concrete over operating temp (-20-C to 50-C/-4-F to 122-F) per MIL STD 810H

Image Sensor TypeImager
Illumination TypeLED
Wireless ChargingYes
Illumination ColorGreen
Google Mobile Services (GMS)Yes
Scanning Capability1D
2D


Memory

Flash Memory128 GB
Standard Memory6 GB
Memory Card SupportedUFS
microSD

Processor & Chipset

Processor Speed2.40 GHz
Processor ModelQCM4490
Processor CoreOcta-core (8 Core)
Processor ManufacturerQualcomm

Battery Information

Battery ChemistryLithium Ion (Li-Ion)
Battery Capacity7000 mAh
Battery IncludedYes
Battery Voltage3.63 V
Removable BatteryYes

Network & Communication

BluetoothYes
Wireless LANYes
Wireless LAN StandardIEEE 802.11 a/b/g/n/ac/ax/d/h/i/r/k/v/w/mc (Wi-Fi 6)
Bluetooth StandardBluetooth 5.3 BLE
Near Field Communication (NFC)Yes

General Information

Product TypeHandheld Terminal
Manufacturer Part Number946400005
Manufacturer Website Address datalogic
ManufacturerDatalogic S.p.A
Product ModelX40
Product NameSkorpio X40 Handheld Terminal
Product LineSkorpio X4
Product SeriesX
Brand NameDatalogic

Miscellaneous

Application/UsageManufacturing
Order Picking
Price Management
Proof of Delivery/Pickup (Signature & Photo)
Retail
Transportation
Warehouse
Work Order Management
Logistics
Inventory Management
Industrial
Healthcare
Asset Tracking
Package ContentsSkorpio X40 Handheld Terminal
Battery

Ingress Protection (IP) RatingIP67
IP65
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
