Elo Touch Solutions E384627. Type: Built-In Bar Code Reader Scanner Type: 1D/2D E384627

Elo Touch Solutions E384627. Type: Built-in bar code reader, Scanner type: 1D/2D, Sensor type: LED. Connectivity technology: Wired. Product colour: Black. Weight: 32 g, Width: 118.5 mm, Depth: 35.5 mm. Package weight: 132 g Improve self-service and price-checker applications with the Elo Edge Connect 2D Barcode Scanner. This fast, hands-free device provides rapid and accurate scanning of barcodes, including linear barcodes and QR codes. Whether on paper, etched into a product or on a mobile screen, the reader can return quick, reliable results. Easy Installation Built on the Elo Edge Connect platform, the 2D Barcode Scanner can be easily integrated with a variety of Elo touchscreens. Simply attach and get started. Modular Our modular design provides our customers with the building blocks to configure a multitude of solutions - making it easy to deploy a variety of solutions from price checkers and self-checkout to visitor management. Start changing the way your customers and employees interact in-store and at work by deploying a new generation of interactive technologies. Next Gen Price Checker Elo---s price-checking solutions deliver exactly what the customer wants, when they want it. By pairing Elo---s 2D Barcode Scanner with an Elo interactive display, retailers can offer price checking plus in-depth product information, virtual customer service, endless aisle and related item recommendations, wayfinding, BOPIS, loyalty and assisted selling. Simplify Employee & Visitor Management Streamline visitor management by allowing guests to scan barcodes and QR codes on their badges or personal devices to gain entry. From hospitals to corporate offices, secured, contactless entry solutions simplify employee and guest screening and automate access. With Elo---s modular platform and wide range of Edge Connect accessories, organizations can easily configure a visitor management solution to meet their access control requirements. Self-Service Checkout Self-service allows customers to take control of their experience while limiting close interaction with employees. With Elo---s 2D Barcode Scanner, customers can scan products and coupons to add to their cart as well as scan their personal device to add loyalty discounts and process secure payment with a mobile wallet. With Elo, it---s easy to configure and deploy the self-checkout kiosks businesses need.
Interfaces/Ports

Host InterfaceUSB

Power Description

Power Supply IncludedNo

Miscellaneous

Application/UsagePrice Checking
Retail
Self Service
CompatibilityI-Series for Android
I-Series for Windows
EloPOS
Touchscreen Monitors - 1002L, 1302L, 1502L, 1902L, 1903LM, 2002L, 2202L, 2203LM, 2402L, 2403LM, 2702L, 2703LM
Touchscreen Signage - 3202L, 3203L, 4202L, 4303L, 4602L, 5053L, 5502L, 5503L, 5553L, 6553L


Technical Information

Barcode Symbology Supported1D :
All major 1D

2D : PDF417
MicroPDF417
Data Matrix
MaxiCode
QR Code
Micro QR Code
Aztec
Grid Matrix
DotCode
Macro PDF

Connectivity TechnologyPlug-in Card
Scanning Distance762 mm
Image Sensor TypeCMOS
Scan Engine ModelSE4720
Scanning Capability2D
1D
Field of View (Horizontal)48??
Field of View (Vertical)30??
Reading Angle (Skew)48??


General Information

Product TypeBarcode Scanner
Manufacturer Part NumberE384627
elotouch
ManufacturerElo Touch Solutions, Inc
Product ModelE384627
Product NameElo Edge Connect 2D Barcode Scanner
Brand NameElo

Physical Characteristics

Weight (Approximate)32 g
Form FactorModular
Height35.6 mm
Width119.4 mm
Depth20.3 mm
Product ColorBlack
Color FamilyBlack
