Intel BX8071514900K Intel Core i9-14900K BX8071514900K

Features



Commodity Classification Automated Tracking System (CCATS)



740.17B1


CPU configuration (max)



1


Direct Media Interface (DMI) Revision



4.0


Embedded options available



No


Execute Disable Bit



Yes


Export Control Classification Number (ECCN)



5A992C


Idle States



Yes


Market segment



Desktop


Maximum number of PCI Express lanes



20


PCI Express configurations



1x16+1x4, 2x8+1x4


PCI Express slots version



4.0, 5.0


Scalability



1S


Supported instruction sets



AVX 2.0, SSE4.1, SSE4.2


Thermal Monitoring Technologies



Yes


Thermal solution specification



PCG 2020A


Use conditions



Workstation, PC/Client/Tablet


Graphics



Discrete graphics card



No


Discrete graphics card model



Not available


Multi-Format Codec Engines



2


Number of displays supported (on-board graphics)



4


Number of execution units



32


On-board graphics card



Yes


On-board graphics card base frequency



300 MHz


On-board graphics card DirectX version



12.0


On-board graphics card dynamic frequency (max)



1650 MHz


On-board graphics card maximum resolution (DisplayPort)



7680 x 4320 Pixels


On-board graphics card maximum resolution (eDP - Integrated Flat Panel)



5120 x 3200 Pixels


On-board graphics card maximum resolution (HDMI)



4096 x 2160 Pixels


On-board graphics card model



Intel UHD Graphics 770


On-board graphics card OpenGL version



4.5


On-board graphics card outputs supported



Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1


On-board graphics card refresh rate at maximum resolution (DisplayPort)



60 Hz


On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)



120 Hz


On-board graphics card refresh rate at maximum resolution (HDMI)



60 Hz


Logistics data



Harmonized System (HS) code



8542310001


Memory



ECC



Yes


Maximum internal memory supported by processor



192 GB


Memory bandwidth (max)



89.6 GB/s


Memory channels



Dual-channel


Memory types supported by processor



DDR4-SDRAM, DDR5-SDRAM


Non-ECC



Yes


Operational conditions



Tjunction



100 �C


Other features



Graphics output



eDP 1.4b, DP 1.4a, HDMI 2.1


L2 cache



32768 KB


Maximum internal memory



192 GB


Package dimensions



Gross Weight (Package, kg)



1.16 kg


Processor



Box



Yes


Cooler included



No


Efficient cores



16


Efficient-core base frequency



2.4 GHz


Efficient-core boost frequency



4.4 GHz


Maximum number of DMI lanes



8


Maximum turbo power



253 Watt


Memory bandwidth supported by processor (max)



89.6 GB/s


Performance cores



8


Performance-core base frequency



3.2 GHz


Performance-core boost frequency



5.6 GHz


Processor ARK ID



236773


Processor base power



125 Watt


Processor boost frequency



6 GHz


Processor cache



36 MB


Processor cache type



Smart Cache


Processor codename



Raptor Lake


Processor cores



24


Processor family



Intel� Core� i9


Processor generation



Intel Core i9-14xxx


Processor manufacturer



Intel


Processor model



i9-14900K


Processor operating modes



64-bit


Processor socket



LGA 1700


Processor threads



32


Stepping



B0


Processor special features



Enhanced Intel SpeedStep Technology



Yes


Intel 64



Yes


Intel Turbo Boost Max Technology 3.0



Yes


Intel Virtualization Technology (VT-x)



Yes


Intel Virtualization Technology for Directed I/O (VT-d)



Yes


Intel VT-x with Extended Page Tables (EPT)



Yes


Intel� Adaptive Boost Technology



Yes


Intel� AES New Instructions (Intel� AES-NI)



Yes


Intel� Boot Guard



Yes


Intel� Clear Video HD Technology (Intel� CVT HD)



Yes


Intel� Control-flow Enforcement Technology (CET)



Yes


Intel� Deep Learning Boost (Intel� DL Boost)



Yes


Intel� Gaussian & Neural Accelerator (Intel� GNA) 3.0



Yes


Intel� Hyper Threading Technology (Intel� HT Technology)



Yes


Intel� OS Guard



Yes


Intel� Quick Sync Video Technology



Yes


Intel� Secure Key



Yes


Intel� Speed Shift Technology



Yes


Intel� Standard Manageability (ISM)



Yes


Intel� Thermal Velocity Boost



Yes


Intel� Thermal Velocity Boost Frequency



6 GHz


Intel� Thread Director



Yes


Intel� Turbo Boost Max Technology 3.0 frequency



5.8 GHz


Intel� Turbo Boost Technology



2.0


Intel� Volume Management Device (VMD)



Yes


Product dimensions



Net Weight (Product, kg)



0.89 kg


Technical details



Launch date



Q4'23


OpenCL version



3.0


Status



Launched


Vendor information



Brand Name


Intel


Warranty



1 Year(s)


Weight & dimensions



Processor package size



45 x 37.5 mm
