Intellinet
Intellinet 561822 Network Switch Gigabit 561822
- UPC:
- 0000000000000
- MPN:
- 561822
- Condition:
- New
- Availability:
- Available to Order: 3 - 4 weeks leadtime
Description
Desktop 5-Port PoE Switch with Gigabit Uplinks - Supports 10/100/1000 Mbps, Power over Ethernet 802.3at
The 5-Port Gigabit Ethernet PoE+ Switch with SFP Port from Intellinet Network Solutions passes both data and electrical power to a number of PoE-compatible devices via standard Cat5e or Cat6 network cables. Equipped with five Gigabit Ethernet ports - four of which are high-power PoE+ PSE ports - this switch can power wireless LAN access points and bridges, VoIP phones, IP video cameras and more while delivering network speeds of up to 1000 Mbps.
High-power PoE+ with output up to 30 watts
This switch supports the IEEE 802.3at protocol and can inject up to 30 watts of power per port. IEEE802.3af- or IEEE802.3at-compliant devices attached to the switch require no additional power, which eliminates the time and expense of electrical rewiring and minimizes the unsightly clutter caused by power supplies and adapters in awkward places such as ceilings and walls. Any mix of PoE and non-PoE devices is supported, and thanks to its short circuit, overload and high-voltage protection function, your equipment is well-protected.
Gigabit Uplinks
The switch is equipped with one Gigabit RJ45 and one SFP transceiver module slot. These Gigabit uplink ports are ideal for connecting the switch to the network's backbone, a server or, perhaps, your video recording solution (NVR).
Wall-mount option
For full installation flexibility, you can mount the switch on the wall through its four built-in holes or use the included non-slip rubber feet to place it on a desktop.
Data transmission
Forwarding rate
8928 Mpps
MAC address table
2000 entries
Store-and-forward
Yes
Switching capacity
12 Gbit/s
Design
Certification
FCC Class A, CE, RoHS, UKCA, NDAA
Housing material
Metal
LED indicators
Activity, Link, PoE, Power
Product colour
Black
Rack mounting
No
Wall mountable
Yes
Network
10G support
No
Copper ethernet cabling technology
10BASE-T, 100BASE-TX, 1000BASE-T
Flow control support
Yes
Networking standards
IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Operational conditions
Operating relative humidity (H-H)
20 - 85 %
Operating temperature (T-T)
0 - 40 °C
Storage relative humidity (H-H)
5 - 90 %
Storage temperature (T-T)
-10 - 70 °C
Package dimensions
Gross Weight (Package, kg)
1.3 kg
Packaging data
Cables included
AC
Manual
Yes
Performance
Fanless
Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
5
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity
1
Power
AC input frequency
50 - 60 Hz
AC input voltage
100 - 240 V
Power consumption (max)
96 Watt
Power source
AC
Power supply included
Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
Total Power over Ethernet (PoE) budget
91 Watt
Product dimensions
Net Weight (Product, kg)
1 kg
Product Depth
8.6 cm
Product Height
2.9 cm
Product Width
15.3 cm
Vendor information
Brand Name
Intellinet
Warranty
1 Year(s)
