Netgear 8X1G Poe+ 220W And 2Xsfp+ Managed Switch. Switch Type: Managed Switch La GSM4210PX-100EUS

NETGEAR 8x1G PoE+ 220W and 2xSFP+ Managed Switch. Switch type: Managed, Switch layer: L2/L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 16000 entries, Switching capacity: 24 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE.... Power over Ethernet (PoE). Rack mounting The NETGEAR AVLine M4250 series was designed with input from AV Professionals. The result is a line of switches built from the ground upto support 1Gb audio and video over IP with customized hardware and software along with dedicated service and support. NETGEAR M4250 series :Ranges from 8 to 48 ports with a variety of PoE+ and Ultra90 PoE++ options for 15.4W, 30W, 60W, 75W and 90W AVoIP endpoints Uplink options include1G for audio installations or standalone video installations as well as 10G uplinks for larger scale video deployments Also includes12-port multi-gigabit Ethernet and 16-port 1G/10G fiber models for plug and play aggregation in a star topology Rack moun tmodels designed for a clean integration with traditional, rack-mounted, AV equipment The M4250 switches come with a sleek, black display panel with status in front and all cabling plus additional status in the back Reversed mounting is possible when ports are desired on the front of the rack A second pair of rack mount ears allows the switches to be mounted recessed by 2-inches to allow for the cabling Software-controlled fan adjustments enable the fans to be turned off when ambient temperature and PoE loads are appropriate for a totaly fanless operation Threaded holes on the bottom (4xM5 for 50x100mm VESA) and in front (1xM10 for clamps) allow for universal mounting option soutside the rack as well New!M4250 desktop versions for use outside of the AV racks in conference rooms, mobile studios, on the wall, under a table or behind a screen NETGEAR M4250 series AV software features: Pre-configured for audio and video over IP out of the box, the M425 switches enable encoders and decoders to be connected with zero configuration When more configuration is required, an AV web-based GUI is available This interface has been specially designed for AV installers with specific AV-related controls made more accessible and with port-based profiles For audio, profiles for Dante, Q-SYS and AES67 are built-in, as well as an AVB profile (AVB license sold separately) For video, the M4250 offers profiles for NVX, SVSI, Q-SYS, NDI, Kramer KDS, Aurora Multimedia, ZeeVee, Atlona, Dante and SDVoE Other AV CODECs and manufacturers are supported as well as audio/video/control mixed profiles To further simplify star deployments, NETGEAR IGMP Plus--- brings multicast automation between all M4250 switches,and with M4300/M4500 With Auto-Trunk and Auto-LAG, simply connect M4250 switches together and you are done!
Management & Protocols

ManageableYes

Technical Information

FeaturesFanless

I/O Expansions

Expansion Slot TypeSFP+
Number of SFP+ Slots2
Total Number of Expansion Slots2.0

Power Description

Power SourcePower Adapter
PoE (RJ-45) PortYes
PoE Budget220 W

Physical Characteristics

Form FactorDesktop
Height40 mm
Width210 mm
Depth140 mm

Network & Communication

Layer Supported3
Networking StandardsIEEE 802.3ad
IEEE 802.3az
IEEE 802.3bt
IEEE 802.3af
IEEE 802.3at
IEEE 802.1Qav
IEEE 802.1Qat
IEEE 802.1AX
IEEE 802.1as
IEEE 802.1ak


Interfaces/Ports

Network (RJ-45)Yes
Uplink PortYes
Total Number of Network Ports8
Port/Expansion Slot Details8 x Gigabit Ethernet PoE+ (220W) Ports
2 x SFP+ 1G; 10G Ports

Media & Performance

Network Technology10/100/1000Base-T GBase-X GBase-T
Ethernet TechnologyGigabit Ethernet Gigabit Ethernet
Media Type SupportedOptical Fiber
Twisted Pair

General Information

Product TypeEthernet Switch
Manufacturer Part NumberGSM4210PX-100EUS
netgear.co.uk
ManufacturerNetgear, Inc
Product ModelGSM4210PX-100EUS
Product NameAV Line M4250 GSM4210PX-100EUS Ethernet Switch
Product LineAV Line
Product SeriesM4250
Brand NameNetgear
