Newland Hr10 Retail Distribution Sorting Hospitality Handheld Barcode Scanner Ca NLS-HR1060-70F

Newland HR10 Retail, Distribution, Sorting, Hospitality Handheld Barcode Scanner - Cable Connectivity - 300 scan/s - 1D - Linear - Serial, USB - Power Supply Included - IP42 Delivers outstanding value. Designed as an entry-level 1D barcode scanner, the HR10 Sardina provides excellent value for everyday use. The device is easy and comfortable to use and can stand up to everyday drops and bumps, making it a reliable investment. Reduces the need for training. Intuitive to use, the HR10 Sardina requires little to no set up or training. From the moment the device is taken out of the box, employees can comfortably use the device all day due to its light design, speed and simplicity. It is equipped with a fast and accurate Newland 1D scanning engine. The result? Aggressive linear barcode reading that eliminates delays in scan-intensive applications. Built for the task at hand. From barcodes printed on paper to barcodes displayed on a smartphone screen, the HR10 Sardina scans virtually all linear barcodes with ease. Its ability to read barcodes from a distance improves worker comfort when scanning larger boxes or out-of-reach products in a cart. Foldable stand available. A foldable stand is available either as an accessory or as a set that includes both the scanner and stand. Application scenarios. Retail chains, office automation, mail/parcel sorting, distribution.
Interfaces/Ports

Host InterfaceUSB
Serial

Power Description

Input Current10 mA
Standby Current14 mA
Power Supply IncludedYes

Technical Information

Barcode Symbology Supported
1D:All major 1D symbologies
Including EAN-13
EAN-8
UPC-A
UPC-E
ISSN
ISBN
Codabar
Code 128
Code 93
ITF-6
ITF-14
Interleaved 2 of 5
Industrial 2 of 5
Standard 2 of 5
Matrix 2 of 5
GS1 Databar
Code 39
Code 11
MSI-Plessey
Plessey.

Connectivity TechnologyCable
Drop Specification
1.2m

Scan Rate300 scan/s
Image Sensor TypeCCD
Linear
Illumination TypeLED
Scan ModeTrigger/Sense
Illumination ColorRed
Scanning Capability1D
Field of View (Horizontal)38??
Reading Angle (Skew)60??
Reading Angle (Pitch)60??
Reading Angle (Roll)30??
Minimum Print Contrast30%
Maximum Element Resolution (Code 39)0.13 mm


Miscellaneous

Application/UsageSorting
Retail
Healthcare
Distribution
Hospitality
Ingress Protection (IP) RatingIP42

Physical Characteristics

Weight (Approximate)190 g
Form FactorHandheld
Length101 mm
Height145 mm
Width68 mm
Product MaterialAcrylonitrile Butadiene Styrene (ABS)

General Information

Product TypeBarcode Scanner
Manufacturer Part NumberNLSHR106070F
newland-id
ManufacturerNewland
Product ModelHR10
Product NameHR10 Sardina Handheld Scanner
Brand NameNewland
