Startech 10/100 Mbps Multi Mode Fiber Media Converter Sc 2 Km Convert And Extend ET90110SC2

StarTech 10/100 Mbps Multi Mode Fiber Media Converter SC 2 km - Convert and extend a 10/100 Mbps Ethernet connection up to 1.2 miles/2km over Multi Mode SC fiber - fiber converter - Ethernet Media Converter -Fibre Converter - 10/100 media converter - UTP to fiber The ET90110SC2 10/100 Mbps Multimode Fiber Media Converter SC (2 km) lets you extend a Fast Ethernet network (10/100Mbps) over multimode fiber, at distances up to 2 km (1.2 miles). A cost-effective solution for connecting a 10/100 Mbps Ethernet (10/100Base-T) network to remote network segments over a 100Base-FX fiber backbone, the media converter is designed to offer a durable and convenient Ethernet-to-fiber solution, featuring an all-steel chassis, and a simple plug-and-play installation with minimal configuration required. For added versatility, this fiber media converter supports standalone operation, or installation into the 20 Slot, 2U Rackmount Chassis (ETCHS2U). Backed by a StarTech 2-year warranty and free lifetime technical support. More from the Manufacturer More from the Manufacturer
Network & Communication

Network Technology100Base-FX /100Base-TX
Ethernet TechnologyFast Ethernet

Power Description

Input Voltage12 V DC
Power SourceAC Adapter
Plug/Connector TypeType M

Media & Performance

Maximum Distance Supported2 km
Media Type SupportedOptical Fiber
Twisted Pair
Fiber Mode SupportedMulti-mode
Fiber Optic Cable Wavelength1310 nm

Interfaces/Ports

USBNo
DVINo
Number of Network (RJ-45) Ports1
Network (RJ-45)Yes
Parallel PortNo
Digital AudioNo
Number of SC Ports1
Digital Audio/VideoNo
Total Number of Ports2
SC Port TypeDuplex


Miscellaneous

Package Contents10/100 Mbps Multi Mode Fiber Media Converter SC 2 km
1 x Universal Power Adapter
1 x Instruction Manual

Compatibility
ETCHS2U Rackmount Chassis

Certifications & StandardsIEEE 802.3
IEEE 802.3u
FC
FCC

Environmentally FriendlyYes
TAA CompliantYes
Environmental ComplianceRestriction of Hazardous Substances (RoHS)

General Information

Product TypeTransceiver/Media Converter
Manufacturer Part NumberET90110SC2
startech/uk
Packaged Quantity1 Each
ManufacturerStarTech
Product Name10/100 Mbps Multi Mode Fiber Media Converter SC 2 km
Brand NameStarTech

Physical Characteristics

Weight (Approximate)391.2 g
Form FactorDesktop
Rack-mountable
Height22.9 mm
Width86.4 mm
Depth152.4 mm
Product ColorBlack
Color FamilyBlack
