Startech 100Ft 30.4M Hdmi 2.1 Hybrid Active Optical Cable Aoc Cmp Plenum Rated 8 8K-A-100F-HDMI-CABLE

StarTech 100ft (30.4m) HDMI 2.1 Hybrid Active Optical Cable (AOC), CMP, Plenum Rated, 8K Ultra High Speed HDMI 2.1/2.0 Cable, 48Gbps - 100ft Hybrid AOC HDMI 2.1 Cable supports 8K 60Hz; CMP-rated for plenum spaces; Shielded Gold-plated connectors; Aramid-reinforced fiber core; Unidirectional; HDMI 2.1 w/HBR3/FRL/HDR10+/DSC 1.2a/HDCP 2.3; 48Gbps; 8K 60Hz/4K 120Hz; 4.6mm O.D. Route this Ultra High Speed HDMI 2.1 Hybrid Active Optical Cable (AOC) through office plenum spaces for long distance transmission of 8K 60Hz video and high quality audio. Hybrid AOC Construction The HDMI 2.1 AOC features a hybrid construction consisting of fiber optic cores and copper conductors. This enables the offloading of low-bandwidth signals (EDID/HDCP/eARC) to maintain high-bandwidth transmission of 8K 60Hz video over fiber. The fiber optic inner cores and shielded copper conductors greatly reduce EMI for optimal signal quality across longer distances. Full-Featured HDMI 2.1 The 8K HDMI Fiber Optic Cable supports full HDMI 2.1 specifications:High Bit Rate 3 (HBR3) supports up to 48Gbps bandwidth for higher refresh rates High Dynamic Range (HDR10+) with 12-bit processing for higher contrast ratio and vibrant, cinematic picture quality Enhanced Audio Return Channel (eARC) for uncompressed 7.1 and 32-channel audio Display Stream Compression 1.2a (DSC) for maximum resolution output Forward Error Correction to manage data transmission errors High-Bandwidth Digital Content Protection (HDCP 2.3) for a secure connection between source and display Flexible Plenum-Rated Cabling This Plenum-Rated HDMI 2.1 Cable features a CMP-rated cable jacket with low-smoke and flame characteristics. It is ideal for use in plenum spaces in buildings (e.g., ceilings and in-wall installations). The optical fiber core is reinforced with Aramid strands for tensile strength, and is rated to withstand over 6,000 bending cycles at 120 degrees. This protects the cable from damage when routing through tight spaces requiring multiple bends. The 4.6mm (0.18in) cable outer diameter is flexible and slimmer than typical passive HDMI cables, making it suitable for installation in space-constrained environments. Please Note: This cable is unidirectional and must be installed in a specific direction. Please refer to the SOURCE and DISPLAY labels on the HDMI connectors to ensure that each end corresponds with the correct hardware.
Miscellaneous

Application/UsageCommercial
Conference Room
Environmentally FriendlyYes
Environmental ComplianceWaste Electrical and Electronic Equipment Directive (WEEE)

Technical Information

Cable Length30.48 m
Data Transfer Rate48 Gbit/s
Device SupportedAudio/Video Device
Jacket TypeCMR
CMP
Plenum
ShieldingYes
FeaturesActive
HDR10+ Support
HDCP 2.3
HDCP
Flexible
Extended Display Identification Data (EDID)
Enhanced Audio Return Channel (eARC)
Display Stream Compression (DSC) 1.2a
Display Stream Compression (DSC)
AOC Technology
Damage Resistant
Cable TypeHybrid Fiber Optic
Connector Type on First EndHDMI 2.1 Digital Audio/Video - Male
Connector Type on Second EndHDMI 2.1 Digital Audio/Video - Male
Connector PlatingGold
American Wire Gauge28/30 AWG
Connector on First End Details1 x HDMI 2.1 Digital Audio/Video - Male
Connector on Second End Details1 x HDMI 2.1 Digital Audio/Video - Male
Connector Gender on First EndMale
Connector Gender on Second EndMale


General Information

Product TypeA/V Cable
Manufacturer Part Number8KA100FHDMICABLE
startech/uk
Packaged Quantity1 / Each
ManufacturerStarTech
Product NameHybrid Fiber Optic Audio/Video Cable
Brand NameStarTech

Physical Characteristics

Material Details
Copper - Conductor

Jacket MaterialPolyvinyl Chloride (PVC)
Shielding MaterialAluminum-polyester Foil
Product ColorBlack
Color FamilyBlack
Product MaterialZinc Alloy
Copper
