Startech 1M Mini Displayport Cable M/M MDISP1M

1M MINI DISPLAYPORT CABLE - M/M The MDISP1M 1m Mini DisplayPort--- 1.2 cable features 2 Mini DP male connectors, and offers a dependable solution for connecting any Mini DisplayPort-enabled laptop (including Mac?- family of products) to a Mini DisplayPort-equipped monitor. The mDP cable supports high resolutions of up to 4k x 2k (3840 x 2160) @ 60Hz with a maximum HBR2 bandwidth of 21.6 Gbps. The cable also supports Multi-Stream (MST) for daisy chaining multiple monitors and provides optional audio support. The MDISP1M is backed by StarTech's Lifetime Warranty, for guaranteed reliability and ensures that digitally protected content is displayed properly, with both HDCP and DPCP capability. Please note: Newer laptop and desktop computers (e.g. Apple?-) come equipped with Thunderbolt--- ports only. Our Mini DisplayPort Cables can be connected to the Thunderbolt ports, enabling you to connect your Mini DP compatible displays. More from the Manufacturer
Miscellaneous

Environmental ComplianceRestriction of Hazardous Substances (RoHS)

Technical Information

Cable Length1 m
ConductorCopper
Data Transfer Rate21.6 Gbit/s
Device SupportedMonitor
Audio/Video Device
Jacket TypeCMG
ShieldingYes
FeaturesMulti-Stream Transport (MST) Support
EMI Protection
Cable TypeMini DisplayPort
Connector Type on First EndMini DisplayPort 1.2 Digital Audio/Video - Male
Connector Type on Second EndMini DisplayPort 1.2 Digital Audio/Video - Male
Connector PlatingGold
Nickel
American Wire Gauge30 AWG
Supported Resolution3840 x 2400
Connector on First End Details1 x 20-pin Mini DisplayPort 1.2 Digital Audio/Video - Male
Connector on Second End Details1 x 20-pin Mini DisplayPort 1.2 Digital Audio/Video - Male


Physical Characteristics

Weight (Approximate)39.9 g
Shipping Height11.94 mm
Shipping Width199.90 mm
Jacket MaterialPolyvinyl Chloride (PVC)
Product ColorBlack
Color FamilyBlack

General Information

Product TypeA/V Cable
Manufacturer Part NumberMDISP1M
startech/uk
Packaged Quantity1
ManufacturerStarTech
Product Name1m Mini DisplayPort 1.2 Cable M/M - Mini DisplayPort 4k
Brand NameStarTech
PackingBagged
