Startech 2M Displayport 2.1 Cable Vesa Certified Dp54 Displayport Cable 8K 60Hz DP21V-2M-DP54-CABLE

StarTech 2m DisplayPort 2.1 Cable, VESA Certified DP54 DisplayPort Cable, 8K 60Hz, 8K 144Hz/4K 240Hz w/DSC 1.2a, DP 2.1 Monitor Cord - DP 2.1 Cable supports UHBR13.5-enabled DisplayPort devices; DP54 (54Gbps) delivers uncompressed 8K 60Hz/4K 144Hz and higher refresh rates and resolutions with DSC 1.2a; VESA Certified DP 2.1 w/HDR/MST/HDCP 2.3; Latching DP Connectors; TPE Jacket Connect an 8K/4K UHD DisplayPort monitor to a host computer or MST hub, using this VESA-Certified DisplayPort 2.1 DP54 Cable. This cable facilitates high bandwidth video and multi-channel audio and is ideal for 8K workstations, high performance GPUs, and dedicated AV applications including media production and content creation. Seamless Compatibility For seamless operation between DisplayPort-enabled devices, the DisplayPort 2.1 Cable is VESA Certified for guaranteed DP 2.1 and backward compatibility (DP 2.0/1.4/1.2). It supports G-Sync and FreeSync, enhancing Variable Refresh Rate (VRR) performance for optimal picture quality between high-capacity GPUs and supported displays. Durable Design This DisplayPort cable features a flexible TPE outer jacket that is tested to withstand 600 bending cycles at -/+60 degrees, and routes easily around corners and desk edges. Robust strain reliefs enable convenient positioning of the cable, and latching nickel-plated DP connectors attach securely to prevent accidental disconnection. The connectors are rated to operate beyond 10,000 insertions. Supported DisplayPort 2.1 Features: This DP54 DisplayPort cable supports the following DP 2.1 features:UHBR13.5 supports high refresh rates including uncompressed 5K 120Hz and 4K 144Hz DSC-compressed video up to 16K 30Hz / 10K 60Hz / 4K 240Hz 4:4:4 8-bit Uncompressed video resolutions up to 10K 30Hz / 8K 60Hz / 4K 144Hz 4:4:4 8-bit High-Bandwidth Digital Content Protection (HDCP) 2.3 for a secure connection between source and display High Dynamic Range 10 (HDR10) for higher contrast ratio and vibrant picture quality Display Stream Compression (DSC) 1.2a for maximum resolution output Multi-Stream Transport (MST) for daisy-chaining multiple monitors 32 Uncompressed Digital Audio Channels Backward compatible with previous DP versions This DP 2.1 Cable is constructed with braided aluminum mylar shielding to minimize EMI for clear, consistent audio/video output and long-term reliable performance.
Miscellaneous

Compatibility
Apple M-series Pro/Max MacBooks

Environmental ComplianceWaste Electrical and Electronic Equipment Directive (WEEE)
Restriction of Hazardous Substances (RoHS)

Technical Information

Cable Length2 m
Data Transfer Rate54 Gbit/s
Device SupportedMonitor
MacBook
Hub
Workstation
Display
Computer
Audio/Video Device
Notebook
External GPU
Jacket TypeVW-1
ShieldingYes
FeaturesFlexible
HDCP 2.3
Braided
Display Stream Compression (DSC)
Display Stream Compression (DSC) 1.2a
Durable
HDR Support
HDR10 Support
Latching Connector
Multi-Stream Transport (MST) Support
Passive
Strain Relief
Variable Refresh Rate (VRR)
EMI Protection
Cable TypeDisplayPort
Connector Type on First EndDisplayPort 2.1 Digital Audio/Video - Male
Connector Type on Second EndDisplayPort 2.1 Digital Audio/Video - Male
Connector PlatingNickel
Supported Resolution15360 x 8640
Connector on First End Details1 x DisplayPort 2.1 Digital Audio/Video - Male
Connector on Second End Details1 x DisplayPort 2.1 Digital Audio/Video - Male
Connector Gender on First EndMale
Connector Gender on Second EndMale


General Information

Product TypeA/V Cable
Manufacturer Part NumberDP21V-2M-DP54-CABLE
Manufacturer Website Address startech /uk
Packaged Quantity1
ManufacturerStarTech
Product Name2m DisplayPort 2.1 Cable
Brand NameStarTech

Physical Characteristics

Weight (Approximate)138.9 g
Height12.7 mm
Width22.9 mm
Jacket MaterialThermoplastic Elastomer (TPE)
Shielding MaterialAluminum Mylar
Product ColorBlack
Color FamilyBlack
Product MaterialABS
