StarTech.com 15m USB 2.0 Active Extension Cable - M/F USB2AAEXT15M

Extend the distance between a computer and a USB 2.0 device by 15 meters

The USB2AAEXT15M 15m Active USB 2.0 Extension Cable, offers one USB 'A' male connector and one USB 'A' female connector, and provides an active extension of USB 2.0 devices of up to 15-meters (49.2-feet).

An all-in-one cable for overcoming distance restrictions as well as power source limitations, the active USB 2.0 extension cable incorporates bus-powered active circuitry to ensure performance beyond the length limits of standard USB cables.

Up to 4 of these cables can be daisy-chained together, allowing for a total USB extension of up to 60-meters. If necessary, the USB device can be powered from a wall outlet using the Universal AC power adapter (provided with the cable).

The USB2AAEXT15M repeater cable supports the full USB 2.0 bandwidth of 480 Mbps, and is backed by StarTech 's 2-year Warranty.

The StarTech Advantage

- No USB signal loss, even at a distance of up to 49.2 feet (15 meters)
- Power your USB devices directly from the USB port or through the included universal external power adapter
- Daisy chain up to 4 cables together for reaching connection distances of up to 60-meters between your USB 2.0 devices

Specs




Features


USB version

Universal Serial Bus (USB) is an industry standard developed in the mid-1990s that defines the interface used for connection, communication and power supply between computers and electronic devices. Every new version - for example 1.1, 2.0, 3.0 - is much faster than the previous one.

USB 2.0


Connector 1

This is the first connector in the device.

USB A


Connector 2

This is the second connector in the device.

USB A


Connector gender

To distinguish parts on a cable interface, connectors are grouped under genders. Sockets or jacks are considered to be female whilst plugs are referred to as male.

Male/Female


Connector 1 gender

The gender of the first connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the part bearing one or which fits into another being called male.

Male


Connector 2 gender

The gender of the second connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the indented one or the one fitting around the other being called female.

Female


Connector 1 form factor

Straight


Connector 2 form factor

Straight


Connector contacts plating

What the connector contacts are covered with (layer on top).

Nickel


Cable jacket material

Polyvinyl chloride (PVC)


Product colour

The colour e.g. red, blue, green, black, white.

Black


Plug and Play

Indicates whether this product supports is "plug and play". Plug and play is hardware or software that, after being installed ("plugged in"), can immediately be used ("played with"), as opposed to hardware or software which requires configuration.




Power


Input voltage

The voltage (V) which is required to power the product.
0 - 240 V


Input current (max)

0.35 A



Power


Output voltage

5 V


Output current (max)

1 A


Weight & dimensions


Cable length

How long the cable is.
m


Weight

Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.

596 g


Packaging data


Package width

The distance from one side of the packaging to the other.

225 mm


Package depth

The distance from the front to the back of the packaging.

214 mm


Package height

The distance from the top to the bottom of the packaging.

60 mm


Package weight

Weight of the packaged product.

866 g


Packaging content


Quantity per pack

1 pc(s)


Certificates


Compliance certificates

RoHS


Certification

CE, FCC, TAA, REACH


Logistics data


Harmonized System (HS) code

84733080
