Viewsonic LSD401HD Dlp Projector High Dynamic Range Hdr 1920 X 1080 Front 2160P LSD401HD

ViewSonic LSD401HD DLP Projector - High Dynamic Range (HDR) - 1920 x 1080 - Front - 2160p - 20000 Hour Normal Mode - Full HD - 3,000,000:1 - 4000 lm - HDMI - USB - Network (RJ-45) - Business, Education, Commercial, Board Room, Lecture Hall, Public Space, Meeting, Class Room - 3 Year Warranty The LS401HD is part of ViewSonic's Luminous Superior Series, a lamp-free projector lineup designed for commercial and educational environments. It delivers ultra-large projections up to 300" in sharp 1080p Full HD resolution, leveraging high native contrast from a 0.65" DMD chip with DLP technology. Powered by 3rd-generation laser phosphor technology, it offers 4,000 ANSI Lumens brightness and a remarkable lifespan of up to 30,000 hours. Its lamp-free design ensures eco-friendliness and cost-efficiency by reducing power consumption. With features like a 1.3x optical zoom, H/V keystone correction, and 360- projection, the LS401HD supports flexible installation. Centralised LAN control simplifies management, making it an excellent choice for boardrooms, lecture halls, and public spaces. Bright, Compact, Durable The LSD401HD incorporates advanced 3rd-gen laser phosphor technology, enhancing brightness by 20% and achieving better luminous efficiency, all while being 32% more compact and more accessible than the previous generation. Its lamp-free light source offers instant power on/off and a lifespan of up to 30,000 hours without maintenance, ensuring consistent image quality even during extended periods of use. Bright Images for Large Venues Delivering 4,000 ANSI Lumens, the LSD401HD provides vibrant and sharp 1080p FHD projection for meeting rooms, classrooms and golf simulation setups. Unmatched Contrasts, Enhanced Visibility Experience enhanced visuals with the LSD401HD, boasting high contrast thanks to DLP technology and an advanced 0.65" DMD chip from Texas Instruments. This provides deeper blacks and richer depth, ensuring an exceptional viewing experience. Ultra-Large Screen with Lower Cost-per-Inch This easy-to-install projector allows for an image size of up to 300", offering a lower cost-per-inch compared to other types of commercial displays. Save on Costs and Energy With its advanced lamp-free light source, the LSD401HD offers a highly energy-efficient and cost-saving display solution by consuming up to 59% less power than competing projectors. Enhanced Installation Flexibility Equipped with a 1.3x optical zoom, the projector allows users to choose the most ideal set-up location within a range, getting the desired image size without needing to change the existing interior design. Get Perfectly-Shaped Images Effortlessly Horizontal and vertical keystone correction, along with 4-corner adjustment features, eliminate crooked or distorted images for a perfectly proportioned picture every time. Versatile Creative Applications The projector can rotate vertically at any angle, enabling projection onto ceilings, walls, or floors, and its portrait mode further expands its capabilities for projection mapping, staging, and creative advertising applications. Centralised Control for Management Efficiency The LSD401HD is certified for Crestron and Q-SYS, and compatible with AMX, PJ Link, ATEN, and Extron systems, allowing for centralized device management for better operational efficiency.
Audio

Speaker IncludedYes

Warranty

Additional Warranty Information
3 Year Swap [Light source 3 Years or 20,000 hours]


Power Description

Operating Power Consumption143 W
Voltage Frequency60 Hz

Video

Video Signal StandardHDTV
Output Scan Format2160p

Interfaces/Ports

USBYes
HDMIYes
Network (RJ-45)Yes

Lamp

Lamp TypeLaser/Phosphor
Number of Lamps1
Normal Mode Lamp Life20000 Hour

Physical Characteristics

Weight (Approximate)3 kg
Height129 mm
Width286 mm
Depth216 mm

Miscellaneous

Application/UsageEducation
Lecture Hall
Public Space
Commercial
Class Room
Business
Board Room
Meeting
Package Contents4,000 ANSI Lumens 1080p Laser Business/Education Projector
1 x Power Cord
1 x Remote Control
QSG



Technical Information

Projection MethodFront
High Dynamic Range (HDR)Yes
High Dynamic Range (HDR) TypeHDR10
HLG

Projection Lens

Optical Zoom1.3x
Maximum Focal Length21.61 mm
Minimum Focal Length16.90 mm
Maximum Diagonal Image Size7.62 m (300")
Minimum Diagonal Image Size762 mm


Contrast Ratio3,000,000:1
Color Supported1.07 Billion Colors
Maximum Resolution3840 x 2160
Native Resolution1920 x 1080
Standard Mode Brightness4000 lm
Graphic ModeFull HD

General Information

Product TypeDLP Projector
Manufacturer Part NumberLSD401HD
viewsoniceurope /uk/
ManufacturerViewSonic Corporation
Product ModelLSD401HD
Product Name4,000 ANSI Lumens 1080p Laser Business/Education Projector
Brand NameViewSonic
