Asus PRO WS W890-SAGE Socket 4710-2/W890/Ddr5/S-Ata 6Gb/S/Ceb PRO WS W890-SAGE

Product Group:

Motherboards



Manufacturer:

ASUS



SKU:
8238


Product Specifications



Product Name:

ASUS PRO WS W890-SAGE (Socket 4710-2/W890/DDR5/S-ATA 6Gb/s/CEB)



Web Address:

www.asus



Model Number:

PRO WS W890-SAGE



EAN:

4711636390453



Package Type:

Retail



Warranty:

3 Years



BIOS:


512 Mb Flash ROM
UEFI AMI BIOS (text-based)




Chipset:

Intel W890



CPU Interface:

Socket 4710-2



RAM Technology:


DDR5 (Quad Channel)
ECC Registered DIMM (RDIMM)
3DS-RDIMM
Multiplexed Combined Rank DIMM (MRDIMM)




RAM Slots:

4 x 288-pin



PCI Express 4.0 x16:

1



PCI Express 5.0 x16:

5



S-ATA 6Gb/s Port(s):

4



RAID:

Raid 0/1/5/10



M.2 Socket(s):

4 x PCIe Gen 5.0 x4



LAN Speed:


1 x Realtek 10Gb Ethernet
1 x Intel 2.5Gb Ethernet
ASUS LANGuard




On-Board Audio:

Realtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC



Back USB 2.0 Port(s):

2



Back USB4 Port(s) Type-C:

2



Back USB 10Gbps Port(s) Type-A:

6



Back LAN Port(s):

2



Back Audio Jack(s):

2



Back Other Port(s):

2 x DP IN ports



Back Button(s):


1 x BIOS FlashBack
1 x Clear CMOS




Internal I/O Connectors:


1 x 4-pin to 24-pin Main Power connectors
2 x 8-pin PCIe to CPU power connectors
1 x 8-pin PCIe Power connector




24-pin ATX Power:

1



8-pin ATX Power:

2



USB 2.0 Header(s):

2



USB 5Gbps Header(s):

1



USB 20Gbps Header(s):

1



COM Port Header(s):

1



Internal Other Port(s):


2 x Addressable RGB Gen 2 headers
1 x CPU Over voltage jumper
2 x RSVD header(s)/switch(es)
1 x Slow Mode switch
1 x VROC header
1 x Thermal Sensor header




Internal Button(s):


1 x FlexKey
1 x ReTry
1 x Safe Boot
1 x Start




Form Factor:

CEB



Product Width:

280mm



Product Length:

305mm



Package Width:

36cm



Package Length:

37cm



Package Height:
cm



Net Weight:

2.99Kg



Gross Weight:

3.49Kg



Special Features:


Ready for Advanced AI PC: Designed for the future of AI computing, with the power and connectivity needed for demanding AI applications.
Intel- LGA4710-2 Socket Supports up to 86-Core CPUs: Ready for Intel- Xeon- 600 Processors for Workstation.
Ultrafast Connectivity: Four PCIe- 5.0 x16 slots, 10Gb and 2.5Gb LAN ports, four M.2 slots, two rear USB4 40Gbps Type-C, and SlimSAS NVMe support.
CPU and Memory Overclocking: Support for up to 4TB ECC R-DIMM DDR5 memory modules (2DPC).
Robust Power and Thermal Design: 12+2+2+1+2 power stages for the CPU and ready for dual-PSU operation, massive VRM, chipset and M.2 heatsinks with an active fan, M.2 backplate and thermal pad.
Ready for Server-Grade IPMI Remote Management: hardware and software support for ASUS IPMI expansion card, plus ASUS Control Centre Express software for real-time monitoring and management.
Trusted Stability: Validated for extensive compatibility with the latest technologies, an expansive QVL list, and tested for 24/7 operation.




Package Contents:


Motherboard
2 x SATA 6Gb/s cables
1 x Thermistor cable pack
1 x DisplayPort cable
1 x 4-pin to 24-pin adapter cable for ATX power connector
1 x detachable VRM/memory fan bracket kit
1 x Q-connector
2 x M.2 Q-Slide package
2 x M.2 backplate rubber packages
1 x Screw package for M.2 Key E
1 x E2A CPU carrier (for Intel- Xeon- 690 Series Processors)
1 x E2B CPU carrier (for Intel- Xeon- 670/650/630 Series Processors)
1 x ACC Express activation key card
1 x Quick start guide
