Axis 02678-001 M4218-V 02678-001

Compact, varifocal, D/N mini dome with dust- and vandal-resistant casing for easy indoor mounting. 3.6-6.6 mm with remote zoom and focus simplifying the installation. Multiple, individually configurable H.264, H.265 and Motion JPEG streams; 8MP for wide 16:9 view with up to 15 fps. Zipstream for reduced bandwidth and storage. Includes a Deep Learning Processing Unit (DPLU) for advanced analytics. Axis Object Analytics, video motion detection and active tampering alarm. HDMI output. Audio and I/O with compatible Axis portcast accessories. MicroSD memory card slot for local video storage. AXIS Edge Vault for increased Cyber Security

Camera



Angle of rotation



105 �


Camera pan control



Yes


Camera shutter speed



1/71500 - 1/5 Second


Camera tilt control



Yes


Lens viewing angle, horizontal



93 - 47 �


Lens viewing angle, vertical



50 - 26 �


Minimum illumination



0.24 lx


Pan range



-180 - 180 �


Tilt angle range



-40 - 65 �


Design



Form factor



Dome


Housing material



Aluminium, Polycarbonate (PC)


IK code



IK08


International Protection (IP) code



IP42


Mounting type



Ceiling/wall


Product colour



White


Image sensor



Optical sensor size



1/2.8 "


Progressive scan



Yes


Sensor type



CMOS


Lens system



Maximum aperture number



2.6


Minimum aperture number



1.7


Zoom capability



Yes


Network



Bluetooth



No


Ethernet interface type



Fast Ethernet


Ethernet LAN



Yes


Networking standards



IEEE 802.1x, IEEE 802.3af, IEEE 802.3at


Quality of Service (QoS) support



Yes


Wi-Fi



No


Night vision



Night vision



No


Operational conditions



Operating relative humidity (H-H)



10 - 85 %


Operating temperature (T-T)



0 - 40 �C


Storage relative humidity (H-H)



5 - 95 %


Storage temperature (T-T)



-30 - 65 �C


Package dimensions



Depth (package,cm)



13.5 cm


Gross Weight (Package, kg)



0.53 kg


Height (package,cm)



9 cm


Width (package,cm)



12.5 cm


Packaging content



Manual



Yes


Number of cameras



1


Packaging content



Owner authentication key, virtual client license for H.264/H.265


Performance



Built-in processor



Yes


Certification



CSA, UL/cUL, BIS, UKCA, CE, KC, EAC, VCCI, RCM


Connectivity technology



Wired


Day/night mode



Yes


Infrared (IR) cut-off filter



Yes


Languages support



Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese


Number of languages



19


Placement supported



Indoor


PTZ control



Yes


PTZ modes



Digital PTZ


Type



IP security camera


Wide Dynamic Range (WDR)



Yes


Ports & interfaces



Ethernet LAN (RJ-45) ports



1


HDMI ports quantity



1


Power



Power consumption (max)



4.8 Watt


Power consumption (Power over Ethernet (PoE))



3 Watt


Power source type



PoE


Product dimensions



Net Weight (Product, kg)



0.53 kg


Product Height



7.1 cm


Security



Active tampering alarm



Yes


Digest authentication



Yes


IP address filtering



Yes


Mirror



Yes


Network access storage (NAS)



Yes


Password protection



Yes


Pixel counter



Yes


Video motion detection



Yes


Storage



Built-in HDD



No


Card reader integrated



Yes


Compatible memory cards



MicroSD (TransFlash), MicroSDHC, MicroSDXC


Flash memory



512 MB


Internal memory



2048 MB


Vendor information



Brand Name


Axis


Video



Frame rate



15 fps


Maximum resolution



3840 x 2160 Pixels


Noise reduction



Yes


Noise reduction technology



2D noise reduction, 3D noise reduction


Privacy masking



Yes


Total megapixels



8 MP


Video compression formats



H.264, H.265, M-JPEG


Video recording



Yes


Video streaming



Yes


Weight & dimensions



Diameter



12 cm
