Eaton 3P700UI. Ups Topology: Standby Offline Output Power Capacity: 0.7 Kva Outp 3P700UI

Eaton 3P700UI. UPS topology: Standby (Offline), Output power capacity: 0.7 kVA, Output power: 420 W. AC outlet types: C3 coupler, AC outlets quantity: 4 AC outlet(s), USB port type: USB Type A/USB Type-C. Battery capacity: 7 Ah, Battery voltage: 12 V. Form factor: Tower, Product colour: Black, Display type: LED. Compliance certificates: CB, CE, RoHS, WEEE, Certification: IEC/EN 62040-1 IEC/EN 62040-2 IEC/EN 62040-3 CE UKCA Ukr Cm
Battery Information

Replaceable BatteryYes

Warranty

Additional Warranty Information
3 years on electronics and 2 years on battery


Environmental Conditions

Minimum Operating Temperature0??C
Maximum Operating Temperature40??C

Interfaces/Ports

USBYes
Number of USB Ports3

Miscellaneous

Certifications & StandardsIEC 61643-11
IEC 62040-1
IEC 62040-2 C2
IEC 62040-3
IEC 61643-11
T3
PEP Ecopassport
CE
Cm
UKCA

Environmental ComplianceRestriction of Hazardous Substances (RoHS)
Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)

Physical Characteristics

Weight (Approximate)3.90 kg
Form FactorRack/Wall Mountable
Height263 mm
Width81 mm
Depth235 mm

Power Description

Circuit BreakerYes
Input Voltage230 V AC
Output Voltage230 V AC
220 V AC
240 V AC
Input Voltage Range220 V AC - 240 V AC 0 V AC - 284 V AC 4 V AC - 264 V AC
Input Frequency46 Hz
50 Hz
60 Hz
65 Hz
Load Capacity (VA)700 VA
Load Capacity (Watt)420 W


General Information

Product TypeStandby UPS
Manufacturer Part Number3P700UI
powerquality.eaton/UK/
ManufacturerEaton Corporation
Product Model3P700UI
Product NameEllipse 3P700UI 700VA Rack/Wall Mountable UPS
Product LineEllipse
Brand NameEaton

Technical Information

Application/UsageEquipment
Business
Residential
Mobile Device
FeaturesCold Start Function
Surge SuppressionYes
Receptacle TypeUSB Type A
USB Type C
IEC
Number of Battery & Surge Outlets3
Number of Surge-only Outlets1
Receptacle Detail1 x USB Type A
4 x IEC
1 x USB Type C
