Startech 1-Port Pci Express Rs232 Serial Adapter Card Pcie Serial Db9 Controller PEX1S953LP

StarTech 1-port PCI Express RS232 Serial Adapter Card - PCIe Serial DB9 Controller Card 16950 UART - Low Profile - Windows/Linux - 1 port PCI Express RS232 serial controller card w/16950 UART/ASIX AX99100 - Bi-directional speeds 921.6Kbps/port | 256 byte FIFO | 9th data bit - Pin 9 pwr out 5v/12v/none w/up to 2A total - Expansion card w/low profile (Std bracket incl) - Win/Linux This RS232 Serial Adapter Card lets you add an RS232 DB9 serial port to your computer through a PCI Express (PCIe) slot. It enables you to interact with serial devices such as card readers, printers, PIN pads, and modems, at speeds of up-to 921.4Kbps. Maximum Compatibility With broad OS support, including for Windows and Linux, this PCI Express card is easy to integrate into mixed environments. The card comes pre-configured with a low-profile bracket, and includes an optional full-profile bracket, so installation is easy regardless of the case form factor. Experience Optimal Technology This PCIe to serial adapter supports the following features:Compatible with industry standard 16950 UART Supports max baud rate of up-to 921.4Kbps Provides 5/12V power output on Pin 9 when external power is connected 128-byte depth FIFO per transmitter and receiver Supports 9, 8, 7, 6, 5 data bits Asix AX99100 chipset PCI Express 1.1 compliant PEX1S953LP is backed by a StarTech lifetime warranty and free lifetime technical support. More from the Manufacturer More from the Manufacturer
Interfaces/Ports

Number of Serial Ports (External)1

Technical Information

Host InterfacePCI Express x1
Platform SupportedLinux
PC
UART Type16950

Physical Characteristics

Weight (Approximate)45.4 g
Form FactorPlug-in Card
Length99.1 mm
Height149.9 mm
Width66 mm
Card HeightLow-profile


General Information

Product TypeSerial Adapter
Manufacturer Part NumberPEX1S953LP
startech/uk
Packaged Quantity1
ManufacturerStarTech
Product Name1-Port PCI Express Serial Card with 16950 UART - Low-Profile
Brand NameStarTech
